纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-021[03]) - HYDRAULIC LINES, UPPER (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
430 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF03H00007F1 | [1] | PIPE | KOBHyd. Lines, Upp. |
| 2. | LF03H01040D2 | [1] | HOSE ASSY. | KOB |
| 3. | LF03H01041D2 | [1] | HOSE ASSY. | KOB |
| 4. | ZX22M12054 | [1] | HOSE ASSY. | KOB Superseded by part number: ZX22M12055 |
| 5. | YT03H01054P1 | [1] | CONNECTION | KOB |
| 6. | ZA28F18008 | [1] | HYD CONNECTOR | KOB |
| 7. | 2444R399D3 | [1] | ELBOW | KOB |
| 8. | ZH32X12000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOB90 |
| 9. | ZD12P01800 | [1] | O-RING | KOB |
| 10. | YT03H01127P1 | [1] | BUSHING | KOB |
| 11. | LF03H00010F1 | [1] | PIPE | KOBHyd. Lines, Upp. |
| 12. | YJ03H01036P1 | [1] | BUSHING | KOB |
