纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-029[02]) - CONTROL LINES, VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
485 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT42H01128P1 | [1] | ELBOW | KOB |
| 2. | 2444Z3279 | [1] | 90 ELBOW | KOB |
| 3. | ZH32X04000 | [3] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB90 |
| 4. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB90 |
| 5. | PH03H01066P1 | [1] | TEE | KOB |
| 6. | ZH22X06000 | [1] | HYD CONNECTOR | KOB |
| 7. | YN50V00020F1 | [1] | HYDRAULIC OIL FILTER | SMInline |
| 8. | YN50V00020S001 | [1] | | |
| 9. | YN50V00020S002 | [1] | | |
| 10. | YN50V00020S003 | [1] | | |
| 11. | ZD12P01800 | [1] | O-RING | KOB |
| 12. | EW02E01015D4 | [1] | CLIP | KOB |
| 13. | PY01P01043D8 | [6] | CABLE TIE,102mm L | KOB |
| 15. | YN13E01375P1 | [3] | CLIP,M8 x 8.20mm Shank | KOB |
| 16. | ZS18C08080 | [2] | SCREW,Hex, M8 x 80mm | KOBCap |
| 17. | ZW16H08000 | [2] | WASHER | KOB |
| 18. | ZE72X04000 | [2] | PLUG | KOB |
