纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-038[02]) - CONTROL LINES, PROPEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
884 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBody |
| 4. | YN30V00070S192 | [2] | SEAT | KOB |
| 5. | YN30V00070S193 | [2] | BUSHING | KOB |
| 6. | 2441U729S511 | [2] | BALL | KOB |
| 7. | PM30V00019S201 | [2] | COVER | KOB |
| 8. | PM30V00019S202 | [4] | PLUG | KOB |
| 9. | PM30V00019S203 | [4] | CAP | KOB |
| 10. | PM30V00019S210 | [4] | PACKING | KOB |
| 11. | PM30V00019S211 | [4] | O-RING | KOB |
| 12. | YT30V00009S212 | [4] | O-RING | KOB |
| 13. | ZD12P00800 | [4] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 14. | EN30V00045S214 | [4] | ROD | KOB |
| 15. | EN30V00024S217 | [4] | SHIM | KOB |
| 16. | PM30V00019S218 | [4] | SPRING SEAT | KOB |
| 18. | 2436U625S232 | [12] | BALL | KOB |
| 19. | YW30V00001S157 | [3] | PLUG | KOB |
| 20. | 2441U722S490 | [6] | PLUG | KOB |
| 21. | YN30V00001S158 | [2] | PLUG | KOB |
| 22. | ZD12P01100 | [3] | O-RING | KOB |
| 23. | PM30V00019S271 | [4] | CAPSCREW | KOBSCREW Cap |
| 24. | EN30V00045S311 | [4] | SEAT | KOB |
| 25. | EN30V00024S313 | [4] | WASHER | KOB |
| 26. | YN30V00070S324 | [4] | SPRING | KOB |
| 27. | YN30V00070S335 | [4] | SPRING | KOB |
| 28. | PM30V00019S336 | [4] | SPRING | KOB |
| 30. | EN30V00045S414 | [4] | BUSHING | KOB |
| 34. | PM30V00019S501 | [2] | BOOT | KOBBellows |
| . . | PM30V00019R100 | [1] | REPAIR KIT | KOBConsists Of Item: 13(2), 10(4), 11(4), 12(4) |
| . . | YN30V00070R200 | [1] | REPAIR KIT | KOBConsists Of Item: 29(1), 31(1), 33(1), 32(2) Superseded by part number: YN30V00070R300 |
