凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (44.151.01) - RIGHT REAR AXLES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
686 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
9706701
|
[10] |
BOLT,Hex, 3/4" - 10 x 2 1/2", Gr 5
|
PA
|
| 5. |
9627896
|
[4] |
BOLT,Hex, 5/8" - 11 x 1 3/4", Gr 5
|
NH
|
| 6. |
280374
|
[4] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
|
| 7. |
280954
|
[10] |
NUT,3/4"-10, G5
|
NH
|
| 9. |
12034871
|
[4] |
WASHER
|
ZED
5/8" Superseded by part number: 86729275
|
| 10. |
87340
|
[10] |
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
|
NH
|
| 11. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 12. |
80299
|
[4] |
WASHER,0.69" ID x 1.75" OD x 0.13" Thk
|
NH
|
| 13. |
80680
|
[2] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 17. |
87016560
|
[6] |
JAM NUT,Jam, 3/8"-16, G5
|
GFD
|
| 18. |
9148
|
[2] |
LOCK NUT
|
FLX
#10-32, stainless steel
|
| 19. |
51200126
|
[5] |
SCREW
|
FLX
cap 1/2"-20 x 1 1/4" G8
|
| 20. |
113-250
|
[2] |
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5, Full Thd
|
CAS
|
| 21. |
9809
|
[2] |
SCREW,Hex, #10 - 32 x 5/8", SST
|
FLX
mch #10-32 x 5/8" hh ss
|
| 22. |
13919
|
[1] |
SENSOR
|
FLX
shaft
|
| 24. |
21681
|
[2] |
RING
|
FLX
sensor half of 60 tooth
|
| 25. |
22007
|
[5] |
SELF-TAP SCREW
|
FLX
#8 x 5/8" fh b pi
|
| 27. |
87426807
|
[1] |
AXLE HOUSING
|
SAS
32" wheel 4.5"
|
| 32. |
GL-734
|
[1] |
SENSOR
|
FLX
scraper
|
| 33. |
GL-954
|
[1] |
CABLE RETAINER
|
FLX
harness
|
| 34. |
GM-325
|
[1] |
RING
|
FLX
backup
|
