凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (55.424.01) - SENSORS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
498 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
13919
|
[1] |
SENSOR
|
FLX
shaft
|
| 2. |
13976
|
[1] |
SENSOR
|
FLX
shaft
|
| 2. |
425045A1
|
[2] |
NUT
|
FLX
7/8"-20 x 1/4" thick
|
| 3. |
13637V2
|
[1] |
SENSOR
|
SAS
air flow
|
| 4. |
87508154
|
[1] |
SENSOR
|
SAS
Optical Bin Level
|
| 6. |
425096A1
|
[1] |
SENSOR
|
FLX
bin level, sonar Superseded by part number: 84529354
|
| 6. |
84529354R
|
[1] |
REMAN-SENSOR
|
SAS
2280, 2330, Both (1/08-), 3380, 3380, Both (7/08-), All PRECISION AIR CART, bin level, sonar, Reman for New PN 425096A1
|
| 6. |
84529354C
|
[1] |
CORE-SENSOR
|
SAS
Return Number
|
| 7. |
280448A1
|
[1] |
STOP LOCK
|
CAS
3c receptacle connector Superseded by part number: 84817102
|
| 8. |
87696545
|
[1] |
CONTACT HOUSING,Male, 3 Pole
|
SAS
cab plastic rcp 3c
|
| 9. |
223950A1
|
[3] |
ELEC. TERMINAL PIN,Nickel, 0.8 - 1.0mm
|
CAS
18-20awg copper nickel plated Superseded by part number: 87696141
|
| 10. |
225222C1
|
[1] |
ELEC CONNECTOR,Male, 5 Pin
|
IH
plastic 5c receptacle fl Superseded by part number: 87706918
|
| 11. |
225348C1
|
[4] |
ELEC. TERMINAL PIN,Male, 0.75 - 2.00 mm2
|
CAS
pin 16-18awg Superseded by part number: 87695607
|
| 12. |
84068583
|
[1] |
PLUG,12 - 16 Ga, White
|
ZED
connector cavity white plastic Superseded by part number: 87695652
|
| 13. |
87696551
|
[1] |
CONTACT HOUSING,Female, 3 Pole
|
BN
cab plastic plug 3c
|
| 14. |
223952A1
|
[3] |
ELEC. TERMINAL PIN,Nickel, 0.8 - 1.0mm
|
CAS
socket 18-20awg Superseded by part number: 87696954
|
| 100. |
8393
|
[1] |
TESTER
|
SAS
5v & 12v sensors
|
| 100. |
13889V2
|
[1] |
TOOL
|
SAS
signal simulator unit, digital
|
