纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (B118M-14A[1]) - CAMSHAFT, PISTION AND FLYWHEEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
291 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8980931550 | [1] | CAMSHAFT | KOB |
| . . | VI8971021231 | [4] | VALVE | KOBInl |
| . . | VI8970454103 | [4] | VALVE | KOBExh |
| . . | VI8980787921 | [1] | NUT | KOBCm/shf Gear |
| . . | VI9098786260 | [1] | PIN | KOBCm/shf |
| . . | VI8971186561 | [1] | SHAFT | KOBRocker Arm |
| . . | VI8980429440 | [1] | PLUG | KOBRocker Shaft End |
| . . | VI0280506250 | [5] | BOLT | KOBRocker Arm Brkt M6x25 M6x25 |
| . . | VI0280506500 | [5] | BOLT | KOBRocker Arm Brkt M6x50 M6x50 |
| . . | VI8942395010 | [16] | SPLIT COLLAR | KOB |
| . . | VI8970346291 | [8] | VALVE SPRING | KOB |
| . . | VI8942510311 | [8] | BUSHING | KOBSeat; Spr |
| A. | VI8972125180 | [4] | ROCKER ARM | KOB |
| B. | VI8972125200 | [4] | ROCKER ARM | KOB |
| . . | VI8970104850 | [8] | SCREW | KOBAdj, Rocker Arm |
| . . | VI0911115060 | [8] | NUT | KOBAdj Screw, Lk |
| . . | VI8970695753 | [8] | PUSH ROD | KOB |
| . . | VI8971243690 | [8] | TAPPET | KOBVlv [ A ], Start Serial: 200711- Superseded by part number: 47543920 |
| . . | VI8970346301 | [8] | TAPPET | KOBVlv, Start Serial: 200805- Superseded by part number: 47543920 |
| . . | VI8973296220 | [6] | NUT | KOBRocker Shaft |
| . . | VI8980488890 | [1] | BRACKET | KOBRocker Arm |
| . . | VI8970706982 | [4] | SPRING | KOBRocker Shaft |
| . . | VI9081505160 | [1] | PIN | KOBShaft Set |
| . . | VI8970728290 | [1] | IDLE SHAFT | KOBIdle Gear Superseded by part number: VI8970728291 |
| . . | VI5125350051 | [1] | COLLAR | KOBThrust, Idle Gear |
| . . | VI8972312130 | [1] | IDLER GEAR | KOB |
| . . | VI9091801620 | [1] | SNAP RING | KOB |
| A. | VI9111290830 | [1] | CUP | KOB; Sealing, Camshaft Superseded by part number: VI8970363351 |
| B. | VI8972334290 | [1] | SEAL | KOBCup Camshaft |
| . . | VI9095714140 | [1] | GASKET | KOBCam End |
| . . | VI8972179572 | [1] | FUEL INJECTION PUMP | KOBGear; Inj Pump & Vlv |
| . . | VI8973074044 | [1] | GEAR | KOBInj Pump & Vlv |
| . . | VI0280608600 | [2] | BOLT | KOBCollar |
| . . | VI8970620480 | [1] | RING | KOBCamshaft |
| A. | VI9000906100 | [1] | CAMSHAFT BEARING | KOB |
| B. | VI9000906570 | [1] | CAMSHAFT BEARING | KOB |
| . . | VI9081605100 | [1] | PIN | KOBIdle Shaft |
