凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (33.202.AX[02]) - BRAKING SYSTEM MOUNT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
278 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47979055
|
[1] |
MOUNTING PLATE
|
SAS
Plate Brake system
|
| 2. |
47971755
|
[1] |
PUMP
|
SAS
Brake 2L Reservoir
|
| 3. |
84388675
|
[1] |
ECU
|
SAS
Rate
|
| 4. |
265235
|
[2] |
HYD CONNECTOR,7/16" - 20 ORB x 7/16" - 20 JIC
|
WIN
|
| 5. |
47798526
|
[2] |
HYDRAULIC HOSE
|
SAS
6.3 x 800mm
|
| 6. |
47922305
|
[1] |
WIRE HARNESS
|
SAS
Brake ECU
|
| 7. |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 8. |
87657
|
[4] |
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5
|
NH
|
| 9. |
80680
|
[2] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 10. |
88434
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
NH
|
| 11. |
9850685
|
[4] |
BOLT,Hex, M6 - 1 x 90mm, Cl 8.8
|
NH
Superseded by part number: 190003800038
|
| 12. |
353308
|
[6] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 13. |
47733787
|
[2] |
U-BOLT
|
SAS
M8
|
| 14. |
86629542
|
[4] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 15. |
87502038
|
[3] |
CABLE TIE
|
BN
Small
|
| 16. |
47839737
|
[1] |
SPACER
|
SAS
Valve Block
|
| 17. |
86624182
|
[2] |
WASHER,6.6mm ID x 18mm OD x 1.6mm Thk
|
FOR
|
| 18. |
86508569
|
[2] |
BOLT,Hex, M6 x 70mm, Cl 8.8
|
NH
|
| 19. |
86625263
|
[4] |
WASHER,9mm ID x 20mm OD x 1.6mm Thk
|
ZED
|
| 20. |
425269A1
|
[1] |
DUST CAP
|
FLX
|
| 21. |
86511923
|
[1] |
SCREW,Pan, #10 - 24 x 1"
|
PA
|
| 22. |
47754878
|
[1] |
CONTROL
|
SAS
Braking System
|
| 23. |
259619
|
[1] |
HYD CONNECTOR,3/4" - 16 ORB x 3/4" - 16 ORB
|
WIN
Superseded by part number: 87412765
|
| 24. |
47755740
|
[1] |
ACCUMULATOR
|
SAS
1 Litter
|
| 25. |
86512934
|
[2] |
90 ELBOW,90 Degree, 7/16"-20, 37 Degree x 9/16"-18, O-Ring
|
WIN
Superseded by part number: 00400160
|
| 26. |
163335
|
[1] |
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BEL
|
| 27. |
86502603
|
[1] |
COUPLING
|
WIN
A
|
