纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (HC650[1]) - CYLINDER ASSY, ARM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
286 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT01V00031F1 | [1] | LIFT CYLINDER | KOBAssy, Arm |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTube, Cylinder |
| 3. | YT01V00031S003 | [1] | CYLINDER HEAD | KOBCylinder Head |
| 4. | EN01V00009S004 | [1] | BUSHING | KOB |
| 5. | 2438U716S6 | [1] | SNAP RING | KOB |
| 6. | LF01V00006S006 | [1] | RING | KOBBuffer |
| 7. | 2438U716S15 | [1] | RING | KOBU |
| 8. | YT01V00002S009 | [1] | RING | KOBWiper |
| 9. | ZD12G09000 | [2] | O-RING,89.40mm ID x 95.60mm OD x 3.10mm | KOB |
| 10. | PH01V00018S008 | [1] | BACK-UP RING | KOB |
| 11. | ZD11G09500 | [1] | O-RING,94.40mm ID x 100.60mm OD x 3.10mm | KOB |
| 12. | YT01V00031S012 | [1] | HOLDER | KOB |
| 13. | YJ01V00002S007 | [1] | RING | KOBBack Up |
| 14. | LE01V00001S014 | [1] | BEARING | KOBCushion |
| 15. | YT01V00031S015 | [1] | SEAL | KOBCushion |
| 16. | YT01V00031S016 | [1] | PISTON | KOB |
| 17. | 2438U1379S15 | [1] | SEAL RETAINER | KOBRing |
| 18. | PH01V00018S012 | [2] | RING | KOBSlide |
| 19. | 2438U986S18 | [1] | SET SCREW | KOBSet |
| 20. | 2436U281S37 | [1] | BALL | KOB |
| 21. | YR01V00006S024 | [1] | BEARING | KOBCushion |
| 22. | LF01V00002S024 | [1] | SEAL | KOBCushion |
| 23. | YR01V00006S027 | [2] | STOP | KOBStopper |
| 24. | YR01V00006S026 | [1] | RING | KOBSnap |
| 25. | YT01V01002P2 | [4] | BUSHING | KOB |
| 26. | 2438U721S26 | [4] | SEAL | KOBRing, Wiper |
| . . | YT01V00031R100 | [1] | REPAIR KIT | KOBConsists Of Item 6x1, 7x1, 8x1 |
| . . | YT01V00031R200 | [1] | REPAIR KIT | KOBConsists Of Item 15x1, 17x1, 18x2 |
| . . | YT01V00031R300 | [1] | REPAIR KIT | KOBConsists Of Item 6x1, 7x1, 8x1 |
| . . | YT01V00031R400 | [1] | REPAIR KIT | KOBConsists Of Item 1x1, 25x2, 26x2 |
| . . | YT01V00031R500 | [1] | REPAIR KIT | KOBConsists Of Item 2x1, 25x2, 26x2 |
