纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (HC750-71[1]) - CYLINDER ASSY, DOZER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1007 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF01V00008F1 | [1] | LIFT CYLINDER | KOBAssy, Dozer |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTube |
| 3. | LF01V00008S003 | [1] | PISTON | KOBPiston |
| 4. | LF01V00008S004 | [1] | NUT | KOBLock Nut |
| 5. | LF01V00008S005 | [1] | CYLINDER HEAD | KOBHead |
| 6. | LF01V00008S006 | [2] | RING | KOBWear |
| 7. | LF01V00008S007 | [1] | SEAL | KOB |
| 8. | YT01V00035S008 | [1] | BEARING | KOBSleeve |
| 9. | YT01V00035S009 | [1] | WEAR RING | KOB |
| 10. | YT01V00035S010 | [1] | SEAL | KOB |
| 11. | YT01V00035S011 | [1] | RING | KOBBack Up |
| 12. | YT01V00035S012 | [1] | SEAL | KOB |
| 13. | ZD12P11200 | [1] | O-RING | KOB |
| 14. | ZD85P12000 | [1] | BACK-UP RING | KOB |
| 15. | ZD11G13000 | [1] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOB |
| 16. | YT01V00035S016 | [2] | BEARING | KOB |
| 17. | YT01V00035S017 | [4] | SEAL | KOB |
| 18. | YT01V00035S018 | [2] | FITTING | KOBGrease |
| 19. | YT01V00035S019 | [1] | SEAL | KOBBuffer |
| . . | LF01V00008R100 | [1] | PIPE | KOBRepair Kit Consists Of Item 1x1, 16x2 |
| . . | LF01V00008R200 | [1] | ROD | KOBRepair Kit Consists Of Item 2x1, 16x2 |
| . . | LF01V00008R300 | [1] | REPAIR KIT | KOBConsists Of Item 6x2, 7x1, 10x1 |
