纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (074-18[1]) - MOTOR INSTAL, SWING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
873 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF32W00002F1 | [1] | Motor Instal, Swing | |
| 1. | YT15V00015F1 | [1] | MOTOR | KOBAssy, Hyd |
| 2. | YT32W01003D1 | [1] | PIPE | KOBTube |
| 3. | 2444R1117D100 | [1] | HOSE,6.4mm ID x 1000mm L | KOB |
| 4. | 2444Z2002 | [1] | HYD CONNECTOR | KOB |
| 5. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOB |
| 6. | PY01P01043D3 | [3] | CABLE TIE,188mm L | KOB |
| 7. | ZC46X19011 | [1] | CLIP | KOB |
| 8. | ZM73C10016 | [1] | BOLT,M10x16mm - Course Thread | KOBSems |
| 9. | ZS13C16050 | [8] | SCREW | KOBCap |
| 10. | ZW13H16000 | [8] | WASHER | KOB |
| 11. | ZE82T08000 | [1] | PLUG | KOB |
| 12. | ZG91U02000 | [1] | LUBE NIPPLE | KOBGrease |
