纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (080-18[1]) - VALVE INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
537 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF64H00028F1 | [1] | Valve Instal | |
| 0. | LF30V00004F1 | [1] | CONTROL VALVE | KOBAssy, Serial Range: LF05-04001-LF05-04132 Superseded by part number: YT30V00047F1, YT30V00042F4 |
| . . | LF30V00005F1 | [1] | CONTROL VALVE | KOBValve Assy, Control, Serial Range: LF05-04133-LF05-04244 Superseded by part number: LF30V00005F5 |
| . . | LF30V00005F2 | [1] | CONTROL VALVE | KOBValve Assy, Control, Start Serial: YT05-04245 Superseded by part number: LF30V00005F5 |
| . . | YT64H00093F1 | [1] | CONTROL VALVE | KOBValve Instal |
| 1. | YT64H01149P1 | [1] | BRACKET | KOBBracket |
| 2. | YT64H01170P1 | [1] | BRACKET | KOBBracket |
| 3. | YT64H01164P1 | [1] | STAY | KOBStay |
| 4. | YT64H01153P1 | [1] | STAY | KOBStay |
| 6. | ZM73C12030 | [2] | BOLT,M12x30mm - Course Thread | KOBSems |
| 7. | ZM73C12035 | [11] | BOLT,M12x35mm - Course Thread | KOBSems |
| 8. | YN64H01393D1 | [2] | CAP | KOB |
| 9. | YN64H01391D1 | [1] | CAP | KOB |
