纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (129-17[1]) - RADIO INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
832 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN54E00010F1 | [1] | Radio Instal | |
| A6. | YN17M01072P1 | [1] | CABLE | KOB |
| A7. | 2432Z478D1 | [2] | CLIP | KOB |
| A8. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOB |
| A9. | YN54E00015F2 | [1] | Radio Instal, Serial Range: LF05-04001-LF05-04263 | |
| . . | YN54E00015F3 | [1] | Radio Instal, Start Serial: LF05-04264 | |
| A9-1. | 2420R1089D1 | [4] | BOLT,M5 x 10mm | KOBSems |
| A9-3. | YN17M01262P1 | [4] | SCREW,Phillips Drive, Pan HD, M5 x 10mm | SMTapping |
| A9-4. | YN54E01020P1 | [2] | BRACKET | KOB |
| A9-5. | YN54S00045P1 | [1] | RADIO | KOB, Serial Range: LF05-04001-LF05-04263 Superseded by part number: YN54S00045P2 |
| A9-6. | ZW16P05000 | [4] | WASHER | KOB |
| A9-7. | YN03M01942F2 | [1] | COVER ASSY | KOB |
| A9-8. | YN54S00045P2 | [1] | RADIO | KOBRadio, Start Serial: LF05-04264 |
| A10. | ZM66C06016 | [3] | BOLT | KOBSems |
| . . | YN50E00018F1 | [1] | Switch Instal | |
| B1. | YN17M01282P1 | [5] | CAP | KOB |
| B2. | YN50S00040DB | [1] | SWITCH | KOB(independent Travel) |
