凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (77.100.AB[02]) - 435, 460, 580 BUSHEL, INNER HYDRAULIC AUGER ARM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
237 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47455699
|
[1] |
ARM
|
SAS
Inner Auger, Incl 2 - 8
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Inner Auger Arm, Incl in 1
|
| 3. |
84581553
|
[4] |
BUSHING
|
SAS
Sintered
|
| 4. |
6635
|
[1] |
BUSHING,25.5mm ID x 31.84mm OD x 25.4mm L
|
FLX
Superseded by part number: 87420246
|
| 5. |
CA-250
|
[1] |
PAD
|
FLX
Stop
|
| 6. |
43117
|
[2] |
SCREW,Hex, M6 x 1.0 x 30mm, Cl 8.8
|
NH
Superseded by part number: 87317695
|
| 7. |
87361
|
[2] |
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
|
NH
|
| 8. |
353308
|
[2] |
NUT,M6 x 1.0, Cl 8
|
NH
|
