纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (280-01[1]) - BATTERY ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
580 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT72E00003F1 | [1] | Battery Assy | |
| . . | YT72E00004F1 | [1] | BATTERY | KOBBattery Instal |
| A1. | YT72E01005P1 | [1] | COVER | KOBCover |
| A2. | 2418P5535 | [1] | PLATE | KOB |
| A3. | YT72E01003D1 | [2] | CAPSCREW | KOBSCREW Cap |
| A4. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| A5. | YT72E01006P1 | [1] | PLATE | KOBPlate |
| A6. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOBSems |
| B1. | PW72S00004P1 | [2] | WET BATTERY | KOBBattery [ (115E41R) ] |
| B1. | F565DSW | [2] | WET BATTERY,12V, 700CCA | MKTNew Holland |
| B1. | B27F72W | [2] | WET BATTERY | IHCase USA |
| B1. | CC27F72W | [2] | WET BATTERY | MKTCase Canada |
