纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (283-01[1]) - CONDITIONER ASSY, AIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
978 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT20M00016F1 | [1] | Conditioner Assy, Air | |
| 1. | HX11W08210DX | [2] | FLEXIBLE HOSE | KOB |
| 3. | YT20M01201P2 | [2] | Bracket | |
| 4. | YN20M01494D7 | [1] | BELT | KOBV |
| 5. | ZC16X02000 | [4] | CLIP | KOB |
| 6. | ZM73C10025 | [5] | BOLT,M10x25mm - Course Thread | KOBSems |
| 7. | ZM73C06020 | [2] | BOLT,M6x20mm - Course Thread | KOBSems |
| 8. | ZM73C08020 | [7] | BOLT,M8x20mm - Course Thread | KOBSems |
| 9. | ZS18C08100 | [4] | SCREW,Hex, M8 x 100mm | KOBCap |
| 10. | ZW16P08000 | [4] | WASHER | KOB |
| 12. | YJ21M01003D1 | [1] | FLEXIBLE HOSE | SMTube |
| 13. | YN20M01046D9 | [1] | TUBE,22.10mm ID x 27.00mm OD x 1700.00mm | KOB |
| 14. | 2418Z1333D29 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1450mm Length | KOB |
| 15. | YN20M01094D6 | [1] | TUBE,25mm ID x 30mm OD x 1500mm Length | KOB |
| 16. | YY20M01142P1 | [1] | BRACKET | KOB |
| 17. | 2418Z1333D14 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1600mm Length | KOB |
| 19. | 2418Z1333D6 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1400mm Length | KOB |
| 24. | ZC48X24014 | [1] | CLIP | KOB |
| 25. | PY01P01043D4 | [15] | CABLE TIE,4.80mm W x 251mm L | KOB |
| 27. | YN20M00120F1 | [1] | AIR CONDITIONER | KOBAssy (See Fig No. 290-01-1), Serial Range: LF05-04001-LF05-04259 Superseded by part number: YN20M00140F1 |
| . . | YN20M00123F1 | [1] | AIR CONDITIONER | KOBAssy (See Fig No. 290-01-1), Start Serial: LF05-04260 Superseded by part number: YN20M00140F1 |
| 30. | YN20M01468P3 | [1] | PANEL | SM Superseded by part number: YN20M01468P4 |
| 32. | YX91V00001F1 | [1] | COMPRESSOR,W/ Pulley | KOBAssy, Air (See Fig No. 294-01-1) |
| . . | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOBE80BMSR ASN LF05-04001 - |
| . . | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
| 33. | YN20M01696F1 | [1] | PULLEY,98mm OD | SMAssembly (Includes Tensioner Bolt) |
| 34. | YT20M01060P2 | [1] | CONDENSER | KOB |
| 35. | YT96V00004F1 | [1] | EVAPORATOR | KOBDrier Assy, Air (See Fig No. 292-01-1) |
| 39. | YN50V01015P3 | [1] | CAB FILTER | SM Superseded by part number: YN50V01015P3P |
| 40. | YN52S00044P1 | [1] | SENSOR | SM |
| 49. | YN13E01375P1 | [2] | CLIP,M8 x 8.20mm Shank | KOB |
| 50. | 2444Z1630 | [2] | FITTING | KOBConnector |
| 51. | YT20M01157P1 | [1] | HYD CONNECTOR | KOB |
| 52. | YT20M01179P1 | [1] | HYD CONNECTOR | KOB |
| 53. | 2432R226D13 | [2] | CLIP | KOB |
| 54. | YN20M01514P1 | [1] | GASKET | SMGrommet |
| 55. | YN20M01676P1 | [1] | GASKET | SMGrommet |
| 58. | YT20M01161P1 | [1] | INSULATION | KOB |
| 59. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOB |
| 60. | ZM73C08016 | [4] | BOLT,M8x16mm - Course Thread | KOBSems |
| 61. | ZN18C06005 | [4] | NUT | KOB |
| 62. | YN20M01701P1 | [4] | WASHER | KOB |
| 63. | YN20M01702P1 | [4] | WASHER | KOB |
| 64. | YN20M01703P1 | [4] | RUBBER SEAL | SMRubber |
