纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (013-18[1]) - CYLINDER ASSY, SWING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
673 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | LF01V00007F1 | [1] | HYDRAULIC CYLINDER | KOBAssy, Swing |
| . . | LF42H00014F1 | [1] | Hyd Lines, Cylinder | |
| A1. | LF42H01045P1 | [1] | TUBE | KOB |
| A2. | 2444R1117D090 | [1] | HOSE,6.40mm ID x 900mm L | KOB Superseded by part number: HX21E04090DY |
| A3. | ZA23F18008 | [1] | HYD CONNECTOR | KOB |
| A4. | ZA33F22008 | [1] | ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB |
| A5. | ZH32Z04000 | [1] | ELBOW | KOB |
| A6. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGrease |
| A7. | ZD12P01800 | [2] | O-RING | KOB |
| A8. | PY01P01043D2 | [4] | CABLE TIE,4.60mm W x 202mm L | KOB Superseded by part number: YT50C01100P1 |
| A9. | LF42H01055P1 | [1] | BAND | KOB |
| A10. | YR42H01116P1 | [1] | BAND | KOB |
| A11. | YR43H01003P1 | [1] | CLAMP | KOB |
| A12. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBCap |
| A13. | ZS18C10050 | [1] | SCREW,Hex, M10 x 50mm | KOBCap |
| A14. | ZW16H10000 | [1] | WASHER | KOB |
| A15. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| A16. | 2418R676D14 | [1] | TUBE | KOB |
| . . | LF02B00015F1 | [1] | Cylinder Instal | |
| . . | LF02B00009F1 | [1] | CYLINDER | KOBCylinder Instal |
| B1. | LF02B01019P3 | [1] | PIN | KOB |
| B2. | LF02B01026P2 | [1] | PIN | KOB |
| B3. | LF02B01027P1 | [1] | PLATE | KOB |
| B4. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOB |
| B5. | ZS18C12025 | [2] | SCREW,Hex, M12 x 25mm | KOBCap |
| B6. | 2418T17895 | [1] | WASHER | KOB |
| B8. | ZW16H12000 | [1] | WASHER | KOB |
| B9. | ZW26X12000 | [1] | WASHER | KOB |
| B10. | LF02B01029D1 | [3] | SHIM | KOB(0. 5) |
| B11. | LF02B01029D2 | [3] | SHIM | KOB(0. 9) |
| B12. | LF02B01029D3 | [3] | SHIM | KOB(1. 2) |
