神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (17-016) - CAMSHAFT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
903 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME081645 | [1] | CAMSHAFT | KOBM0 ONLY, Start Serial: 9002- |
| . . | VAME081638 | [1] | CAMSHAFT M0 ONLY, Serial Range: 8906--9001 | CAMSHAFT M0 ONLY, Serial Range: 8906--9001 |
| . . | VAME081512 | [1] | CAMSHAFT | KOBM0 ONLY, Serial Range: --8905 |
| . . | VAME081635 | [1] | CAMSHAFT | KOBM5 ONLY |
| 2. | VAMS476137 | [1] | WOODRUFF KEY | KOBKEY, WOODRUFF 7 X 22 M0 ONLY, Start Serial: 9002- Superseded by part number: VAF287007022 |
| . . | VAMS476139 | [1] | WOODRUFF KEY | KOBKEY, WOODRUFF 7 X 28 M0 ONLY, Serial Range: --9001 |
| . . | VAMS476137 | [1] | WOODRUFF KEY | KOBKEY, WOODRUFF 7 X 22 M5 ONLY Superseded by part number: VAF287007022 |
| 3. | VAME013259 | [1] | PLATE | KOBTHRUST M0 ONLY, Start Serial: 9002- |
| . . | VAME029025 | [1] | PLATE,THRUST M0 ONLY, Serial Range: --9001 | PLATE,THRUST M0 ONLY, Serial Range: --9001 |
| . . | VAME013125 | [1] | PLATE | KOBTHRUST M5 ONLY |
| 4. | VAMF140223 | [2] | BOLT | KOBBOLT, FLANGE 8 X 16 |
