神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (17-046) - OIL LINE 030-280K Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
261 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME084620 | [1] | TUBE | KOBPIPE, OIL |
| 2. | VAMH000119 | [2] | BOLT | KOBBOLT, JOINT 10 X 25 |
| . . | VAMF660063 | [4] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 2A. | VAMH037717 | [1] | BOLT | KOBBOLT, EYE 10 X 20 |
| 3. | VAMH020801 | [1] | CLIP | KOBCLAMP |
| 4. | VAMH000999 | [1] | BOLT | KOBBOLT, FLANGE 6 X 12 |
| 6. | VAMH023891 | [1] | STAY | KOBBRACKET |
| 7. | VAMF140223 | [1] | BOLT | KOBBOLT, FLANGE 8 X 16 |
| 30. | VAME088700 | [1] | PIPE | KOBTURBO INLET, Start Serial: 9105- |
| . . | VAME088547 | [1] | PIPE | KOBPIPE, OIL TURBO INLET, Serial Range: --9104 |
| 32. | VA3003638302 | [1] | CLAMP CLAMP | CLAMP CLAMP |
| 33A. | VAME920041 | [1] | SPACER | KOBL=17 |
| 34. | VAMF140229 | [1] | BOLT | KOBBOLT, FLANGE 8 X 30 |
| 38. | VAMF650102 | [1] | SCREW | KOBBOLT, EYE 10 X 20 |
| 39. | VAME088702 | [1] | RIGID TUBE | KOBTURBO OUTLET, Start Serial: 9105- |
| . . | VAME088576 | [1] | TUBE | KOBTURBO OUTLET, Serial Range: --9104 |
| 43. | VAMF140021 | [1] | SCREW | KOBBOLT, FLANGE 8 X 12 |
| 44. | VAME070510 | [1] | GASKET | KOB, Start Serial: 9105 Superseded by part number: VAME078273 |
| . . | VAME088499 | [1] | GASKET | KOB, Serial Range: --9104 Superseded by part number: VAME300515 |
| 45. | VAMH000931 | [2] | BOLT | KOBBOLT, FLANGE 10 X 18, Start Serial: 9105- Superseded by part number: 132361A1 |
| 46. | VAMF120223 | [2] | BOLT, FLANGE 8 X 16, Serial Range: --9104 | |
| 47. | VAMH035015 | [1] | O-RING | KOBO-RING 17 |
| 55. | VAME070497 | [1] | HYD CONNECTOR | KOB, Serial Range: --9104 |
| 56. | VAME070509 | [1] | GASKET | KOB, Serial Range: --9104 Superseded by part number: VAME300512 |
| 57. | VAMF140225 | [2] | BOLT | KOBBOLT, FLANGE 8 X 20, Serial Range: --9104 |
