神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (05-011) - HEATER ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
473 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N7534F1 | [1] | HEATER ASSY | |
| 1. | 2479U293D3 | [1] | HEAT EXCHANGER | KOBCAR Superseded by part number: 2479U293D4 |
| 2. | R44T0201 | [1] | HYD CONNECTOR | KOB Superseded by part number: 113700-1381 |
| 3. | 2444T2577 | [1] | HYD CONNECTOR | KOBM16x1.5x51mm Long Ø14 Hose |
| 4. | 2444T2610 | [1] | HYD CONNECTOR | KOB |
| 5. | 24100P3364F1 | [1] | SUPPORT ASSY | |
| 5-1. | 2416P16643 | [1] | SUPPORT | |
| 5-2. | 2427Z1515 | [1] | INSULATION, SOUND | |
| 5-3. | 2427Z1516 | [1] | INSULATION, SOUND | |
| 5-4. | 2427Z1517 | [1] | INSULATION, SOUND | |
| 5-5. | 2427Z1518 | [1] | INSULATION, SOUND | |
| 6. | 2416P16123 | [1] | SUPPORT | |
| 7. | 24100N6984F1 | [1] | DUCT ASSY | DUCT ASSY |
| 7-1. | 2427N3112 | [1] | DUCT | KOB |
| 7-2. | 2427Z1519 | [1] | INSULATION, SOUND | |
| 7-3. | 2427Z1520 | [1] | INSULATION, SOUND | |
| 7-4. | 2427Z1521 | [1] | INSULATION, SOUND | |
| 8. | 24100N7275F3 | [1] | BOX | KOBSEE FIGURE 05-012 |
| 9. | 2414P7634 | [1] | COVER | COVER |
| 10. | 2479U325 | [1] | SWITCH | KOB |
| 11. | 2420Z1374 | [6] | PLUG | KOB |
| 12. | 2432R226D11 | [4] | CLIP | KOBClamp, Double -- ID 22 x 81mm Long Superseded by part number: ZC48X22014 |
| 13. | 2432Z290 | [2] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 14. | ZC15X02300 | [4] | CLIP | KOB |
| 15. | R18T0026D30 | [2] | HOSE | KOBID 12 x OD 22 x 3200mm |
| 16. | 2444Z3924D1 | [2] | HOSE | KOB |
| 17. | 2420Z699 | [1] | GROMMET | KOB |
| 18. | 2420Z1188 | [1] | GROMMET | KOB |
| 19. | ZS18C10016 | [4] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| 20. | ZS18C10025 | [5] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 21. | ZW16X10000 | [12] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 22. | ZW26X10000 | [12] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 23. | ZN18C10008 | [3] | NUT | KOBM10x1.50mm |
| 24. | ZS18C08016 | [4] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 25. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 26. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 27. | 2479Z2580 | [1] | HARNESS | |
| 28. | 2444Z3924D3 | [2] | HOSE | KOB |
| 29. | 2444Z3924D5 | [2] | HOSE | KOB |
