久保田零件查询T04500 SPEED CHANGE 1 SPEED CHANGE LEVEREPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
498 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
6620443310
|
[1] |
HOLDER
|
0.6160(lbs); 0.280
|
| 002. |
0112050828
|
[1] |
BOLT
|
0.0000(lbs); 0.000
|
| 003. |
6620443320
|
[1] |
SPRING
|
0.0000(lbs); 0.000
|
| 004. |
6620443330
|
[1] |
HOLDER SPRING
|
0.2090(lbs); 0.095
|
| 005. |
0120250614
|
[3] |
BOLT
|
0.0132(lbs); 0.006
|
| 006. |
6620443343
|
[1] |
ARM
|
0.2860(lbs); 0.130
|
| 007. |
6620443572
|
[1] |
BUSH
|
0.0044(lbs); 0.002
|
| 008. |
6620443352
|
[1] |
SHAFT HOLDER
|
0.1584(lbs); 0.072
|
| 009. |
0112350828
|
[1] |
BOLT
|
0.0308(lbs); 0.014
|
| 010. |
0812106000
|
[1] |
BEARING BALL
|
0.0440(lbs); 0.020
|
| 011. |
0401150100
|
[1] |
WASHER PLAIN
|
0.0044(lbs); 0.002
|
| 012. |
0461200100
|
[1] |
CIR-CLIP EXTERNAL
|
0.0022(lbs); 0.001
|
| 013. |
6620443362
|
[1] |
ROD
|
0.0000(lbs); 0.000
|
| 014. |
0401250080
|
[3] |
WASHER PLAIN
|
0.0022(lbs); 0.001
|
| 015. |
0551150215
|
[2] |
PIN SPLIT
|
0.0022(lbs); 0.001
|
| 016. |
6620443370
|
[1] |
SUPPORT
|
0.5500(lbs); 0.250
|
| 017. |
6620443550
|
[2] |
BUSH
|
0.0000(lbs); 0.000
|
| 018. |
0112050818
|
[3] |
BOLT
|
0.0000(lbs); 0.000
|
| 019. |
6721142940
|
[1] |
NIPPLE GREASE
|
0.0022(lbs); 0.001
|
| 020. |
6620443300
|
[1] |
ASSY PEDAL CHANGE
|
2.6400(lbs); 1.200
|
| 021. |
6620443390
|
[1] |
COVER FRONT
|
0.1320(lbs); 0.060
|
| 022. |
6620443410
|
[1] |
COVER REAR
|
0.1320(lbs); 0.060
|
| 023. |
6620443380
|
[1] |
PEDAL CHANGE
|
2.4200(lbs); 1.100
|
| 024. |
0115550860
|
[1] |
BOLT
|
0.0550(lbs); 0.025
|
| 025. |
0211450080
|
[1] |
NUT
|
0.0110(lbs); 0.005
|
