神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (07-005) - SPRING ASSY. TRACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
861 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N5945F2 | [1] | SPRING | KOBTRACK Superseded by part number: 24100N5945F2M |
| 4. | ZP26D08070 | [1] | ROLL PIN | KOBSPRING |
| 5. | 2417P272 | [1] | SPRING | KOB Superseded by part number: 2417P513 |
| 6. | ZS13C16045 | [2] | SCREW | KOBScrew -- M16x2.0x45mm |
| 8. | 2439P177 | [1] | PISTON | KOB |
| 9. | 2418U130D35 | [1] | PACKING | KOBOIL SEAL |
| 10. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 11. | 2419T4748 | [2] | PIN | KOB Superseded by part number: LQ54D01023P1 |
| 13. | 2416N5791 | [1] | U-BRACKET | KOB Superseded by part number: 2416N5791M |
| 14. | 2420T7344 | [1] | NUT | KOB |
| 15. | 2418T21285 | [1] | COLLAR CLAMP | KOBCOLLAR |
| 16. | 2438N264 | [1] | CYLINDER | KOB |
| 17. | 2444P803 | [1] | LUBE NIPPLE,5/8" - 18 x 64mm L, 19mm Hex | KOB5/8" - 18 UNF, Straight |
