| 1. |
84485892
|
[1] |
WIRE HARNESS
|
BN
Pump Detect, 810 Flex-Air System, Includes Ref 2 - 6
|
| 2. |
87695723
|
[1] |
ELEC CONNECTOR,Male , 3 Pole
|
RAC
Main Frame Harness Interface, X-832M2 Superseded by part number: 87055165
|
| 2. |
87695625
|
[1] |
WIRE CONNECTOR,Locking, Green
|
BN
Main Frame Harness Interface, X-832M2
|
| 2. |
84068583
|
[1] |
PLUG,12 - 16 Ga, White
|
ZED
Main Frame Harness Interface, X-832M2 Superseded by part number: 87695652
|
| 2. |
381417A1
|
[2] |
TERMINAL,Male, Nickel, 0.50 - 1.00mm
|
CAS
Main Frame Harness Interface, X-832M2 Superseded by part number: 87695623
|
| 3. |
84376517
|
[1] |
ELEC CONNECTOR
|
BN
Logic Relay, RL
|
| 3. |
86508603
|
[1] |
RELAY,12V
|
WIN
Logic Relay, RL
|
| 3. |
87688848
|
[4] |
TERMINAL
|
BN
Logic Relay, RL
|
| 4. |
87695582
|
[1] |
ELEC CONNECTOR,Female, 2 Pole
|
RAC
Pump On, Harness Side, X-001F2
|
| 4. |
84074638
|
[1] |
LOCKING TAB,Locking Wedge, Green
|
ZED
Pump On, Harness Side, X-001F2
|
| 4. |
87695921
|
[2] |
CONTACT,Female, Nickel, 0.50 - 1.00mm
|
COE
Pump On, Harness Side, X-001F2
|
| 5. |
84391159
|
[1] |
CAP
|
BN
Cap For Pump On, Harness Side, X-001M2
|
| 6. |
87695584
|
[1] |
CONTACT HOUSING,Male, 2 Cavities
|
RAC
Pump On, Pump Side, X-001M2
|
| 6. |
86500166
|
[1] |
ELEC CONNECTOR
|
ZED
Pump On, Pump Side, X-001M2 Superseded by part number: 225318C1
|
