凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (55.100.18) - PUMP ON ADAPTER HARNESS, 810 FLEX AIR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
805 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87542700
|
[1] |
WIRE HARNESS
|
BN
Pump On, Flex-Air System, Includes Ref 2 - 5
|
| 2. |
225315C1
|
[1] |
ELEC CONNECTOR,Male, 2 Pin
|
IH
Cap For P521, J521 Superseded by part number: 87696073
|
| 2. |
86500166
|
[1] |
ELEC CONNECTOR
|
ZED
Wedge, Cap For P521, J521 Superseded by part number: 225318C1
|
| 2. |
84068583
|
[2] |
PLUG,12 - 16 Ga, White
|
ZED
Cap For P521, J521 Superseded by part number: 87695652
|
| 3. |
225316C1
|
[1] |
ELEC CONNECTOR,Female, 2 Pin
|
IH
P521 Superseded by part number: 87695582
|
| 3. |
87695921
|
[2] |
CONTACT,Female, Nickel, 0.50 - 1.00mm
|
COE
P521
|
| 4. |
84477044
|
[1] |
TERMINAL
|
BN
Terminal, M4 Ring, Fan On -, J1
|
