神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (05-002) - ENGINE ASSY - 2451U344F4 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
508 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2451U344F4 | [1] | ENGINE | KOB |
| 2. | 2489U268F1 | [1] | SENDER UNIT,65 Degrees C, 149 Degrees F - 115 Degrees C, 239 Degrees F | KOBTHERMO |
| 3. | VAME049233 | [1] | RELAY | KOB(INP) Superseded by part number: ME049233 |
| 4. | VAME049232 | [1] | RELAY | KOB(E/G) Superseded by part number: VAME049307 |
| 5. | VAME049209 | [1] | THERMOSTAT | KOB105°C |
| 6. | VAMC840219 | [1] | SWITCH | KOBOIL PRESS SWITCH (EG) Superseded by part number: H411892 |
| 7. | VAMC845235 | [1] | SENDER UNIT | KOBSENSOR, SPEED Superseded by part number: 240067A1 |
| 8. | VAMC840577 | [1] | SWITCH | KOBLEVEL, OIL |
| 9. | VAME035393 | [1] | ELEMENT | KOB Superseded by part number: 47500495 |
| 10. | VAME074013 | [1] | ELEMENT | KOB Superseded by part number: 2451U324-1D |
