神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (05-003) - PUMP ASSY, CONNECT - 24100N6224F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1004 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N6224F2 | [1] | PUMP ASSY, CONNECT | PUMP ASSY, CONNECT |
| 3. | 2416N3333 | [1] | U-BRACKET | KOB |
| 4. | 2418R272F1 | [1] | COUPLING | KOB |
| 4-1. | 2418R219S1 | [1] | ELEMENT | KOB |
| 4-2. | 2418R272S2 | [1] | HUB | KOB |
| 4-3. | 2418R219S3 | [4] | INSERT | KOB |
| 4-4. | 2418R219S4 | [4] | INSERT | KOB |
| 4-5. | ZP26D05010 | [12] | PIN | KOBRoll -- OD 05 x 10mm Long |
| 4-6. | 2418R219S6 | [8] | SCREW | KOB |
| 4-7. | ZS73C16025 | [2] | SET SCREW | KOBScrew, Set -- M16x2.0x25mm |
| 5. | ZS23C20055 | [4] | SCREW,Hex Socket Head, M20 x 55mm | KOBM20x2.5x55mm |
| 6. | ZD12G05500 | [1] | O-RING,3.1mm Thk x 54.4mm ID, 90 Duro | KOBO -- ID 54.40 ± 0.49 x OD 60mm |
| 7. | ZS13C10025 | [2] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 8. | ZW11K10000 | [2] | WASHER | KOBID 10 x OD 18 x Th 2.0mm |
| 9. | 2437U402F1 | [1] | PUMP | KOBASSY |
| 9. | 2437U402F1RMP | [1] | REMAN-HYD PUMP | KOBReman For New PN 2437U402F1 |
| 9. | 2437U402F1C | [1] | CORE-HYDRAULIC PUMP | KOBReturn Number |
| 10. | 2437U157F1 | [1] | HYDRAULIC PUMP | KOBGEAR |
