神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (02-009) - INSULATION, SOUND Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
150 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4232F2 | [1] | INSULATION, SOUND | |
| 1. | 2416T16004 | [1] | SHEET, RUBBER | |
| 3. | 2479T1511 | [10] | INSULATION, SOUND | INSULATION, SOUND |
| 4. | 2416T17151 | [1] | SHEET, RUBBER | SHEET, RUBBER |
| 5. | 2479T1516 | [1] | INSULATION, SOUND | |
| 7. | 2479T1517D2 | [2] | INSULATION, SOUND | |
| 9. | 2479T1517D3 | [2] | INSULATION, SOUND | |
| 10. | 2420Z1042 | [1] | GROMMET | KOB Superseded by part number: 2420Z1301 |
