| . . | 2436U1745F1 | [1] | CONTROL VALVE | KOBASSY, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2436U1745S101 | [1] | CASING | |
| 153. | 2436U749S151 | [2] | PLUG | KOB Superseded by part number: ZE82T06000 |
| 154. | 2436U1745S253 | [2] | PLUG | KOB |
| 155. | 2436U1485S651 | [1] | PLUG | PLUG |
| 162. | 2436U665S262 | [2] | O-RING | KOB Superseded by part number: 2436U1457S162 |
| 163. | ZD12P00700 | [2] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 164. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 165. | ZD12P01200 | [1] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 171. | ZS23C12110 | [8] | SCREW,Hex Socket Head, M12 x 110mm | KOBM12x1.75x110mm Superseded by part number: ZS28C12110 |
| 201. | 2436U1745S201 | [1] | SPRING | |
| 202. | 2436U1745S202 | [1] | COVER | |
| 211. | 2436U1745S211 | [1] | BALL | |
| 231. | 2436U1745S231 | [1] | SEAT | |
| 251. | 2436U585S651 | [1] | PLUG | KOB Superseded by part number: YT30V00009S153 |
| 253. | 2436U1745S253 | [1] | PLUG | KOB |
| 261. | ZD12P01000 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 262. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 271. | ZS23C06025 | [4] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 272. | ZS23C06010 | [4] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 301. | 2436U1745S301 | [1] | SPOOL | |
| 321. | 2436U1745S321 | [1] | SPRING | SPRING |
| 331. | 2436U1745S331 | [2] | SEAT, SPRING | |
| 332. | 2436U665S334 | [1] | SCREW | KOB Superseded by part number: 2436U1431S332 |
| 511. | 2436U666S511 | [4] | POPPET | POPPET |
| 512. | 2436U666S512 | [1] | POPPET | POPPET |
| 521. | 2436U666S521 | [2] | SPRING | SPRING |
| 522. | 2436U1745S522 | [1] | SPRING | KOB |
| 523. | 2436U1745S5253 | [2] | SPRING | |
| 551. | 2436U1485S552 | [5] | PLUG | KOB |
| 561. | ZD12P02200 | [5] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm |
| 601. | 2436U1745S601 | [2] | VALVE, RELIEF | VALVE, RELIEF |
| 901. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| . . | 2436U1745R10 | [1] | REPAIR KIT CONSISTS OF REF 101, 153 - 155, 164, 301, 321, 331, 332, 511, 512, 521 - 523, 551, 165 | REPAIR KIT CONSISTS OF REF 101, 153 - 155, 164, 301, 321, 331, 332, 511, 512, 521 - 523, 551, 165 |
| . . | 2436U1745R20 | [1] | REPAIR KIT | KOBCONSISTS OF REF 202, 211, 231, 251, 261 |
