| . . | 2436U1746F1 | [1] | VALVE, PILOT CONSISTS OF THE FOLLOWING PARTS | VALVE, PILOT CONSISTS OF THE FOLLOWING PARTS |
| 101. | 2436U1746S101 | [1] | CASING | |
| 102. | 2436U1746S102 | [1] | CASING | |
| 151. | 2436U741S462 | [6] | PLUG | KOB |
| 201. | 2436U905S3 | [4] | PLUG | PLUG |
| 210. | 2436U1746S210 | [4] | SEAL | KOB Superseded by part number: 2436U1487S39 |
| 211. | 2436U1746S211 | [4] | MUDSCRAPER RING | KOB Superseded by part number: 2436U905S5 |
| 212. | ZD12G02500 | [4] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 214. | 2436U1746S214 | [4] | ROD, PUSH | ROD, PUSH |
| 301. | 2436U905S8 | [4] | SPOOL | |
| 310. | ZS23C04006 | [4] | SCREW,Hex Socket Head, M4 x 6mm | KOBM04x0.7x06mm |
| 311. | 2436U905S10 | [4] | SEAT, SPRING | |
| 312. | 2436U905S11 | [4] | WASHER | |
| 313. | 2436U905S12 | [4] | WASHER | |
| 320. | 2436U1746S320 | [4] | SPRING | |
| 335. | 2436U905S14 | [4] | SPRING | |
| 412. | 2436U1062S412 | [4] | BUSHING | KOB |
| 413. | 2436U1746S413 | [2] | SHAFT | KOB |
| 420. | 2436U1746S420 | [2] | PEDAL | KOB |
| 421. | 2436U1746S421 | [4] | SCREW | KOB |
| 423. | 2436U1746S423 | [4] | CAPSCREW | CAPSCREW |
| 427. | 2436U1746S427 | [4] | LOCK WASHER | LOCK WASHER |
| 431. | 2436U1746S431 | [2] | BUSHING | KOB |
| 432. | 2436U1746S432 | [8] | CAPSCREW | CAPSCREW |
| 433. | ZS16C10025 | [2] | SCREW | KOBM10x1.50x25mm Superseded by part number: ZS18C10025 |
| 434. | ZS16C10045 | [2] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
| 435. | ZN16C10008 | [4] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 501. | 2436U1746S501 | [4] | BOOT | KOBCOVER BLO BOLT |
| 510. | 2436U1746S510 | [3] | BOLT | |
| 511. | ZN16C08007 | [6] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 521. | ZD12P01200 | [4] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 522. | 2436U1746S522 | [1] | SPACER | |
| . . | 2436U1746R10 | [1] | PILOT VALVE | KOBREPAIR KIT, CONSISTS OF REF 101, 151, 201, 210 - 212, 214, 301, 310 - 313, 320, 335, 412, 421 Superseded by part number: 2436U1746R20 |
| . . | 2436U1746R20 | [1] | PILOT VALVE | KOBREPAIR KIT, CONSISTS OF REF 102, 151, 201, 210 - 212, 214, 301, 310 - 313, 320, 335, 412, 421 Superseded by part number: 2436U1746F2 |
| . . | 2436U1746R30 | [1] | REPAIR KIT CONSISTS OF REF 413, 420, 421, 423, 427, 431, 432 | REPAIR KIT CONSISTS OF REF 413, 420, 421, 423, 427, 431, 432 |
