神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-015) - VALVE ASSY 2436U1832F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
998 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1832F1 | [1] | VALVE ASSY CONSISTS OF THE FOLLOWING PARTS | VALVE ASSY CONSISTS OF THE FOLLOWING PARTS |
| 201. | 2436U1832S201 | [1] | CASING | |
| 202. | 2436U1832S202 | [1] | COVER | |
| 251. | 2436U741S462 | [6] | PLUG | KOB |
| 261. | ZD12P00800 | [13] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 611. | 2436U1832S611 | [1] | SPOOL | |
| 612. | 2436U1832S612 | [1] | SPOOL | |
| 613. | 2436U1832S613 | [1] | PISTON | |
| 615. | 2436U1832S615 | [2] | PISTON | |
| 616. | 2436U1832S616 | [1] | PISTON | |
| 651. | 2436U1832S651 | [2] | PLUG | KOBM18x1.5mm |
| 652. | 2436U1832S652 | [1] | PLUG | |
| 653. | 2436U1832S653 | [1] | PLUG | |
| 661. | ZD12P01600 | [4] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 971. | ZS23C08050 | [3] | CAP,Hex Socket Head, M8 x 50mm | KOBScrew -- M08x1.25x50mm |
| . . | 2436U1832R10 | [1] | VALVE ASSY REPAIR KIT, CONSISTS OF REF 201, 251, 261, 611 - 616, 651 - 653, 661 | VALVE ASSY REPAIR KIT, CONSISTS OF REF 201, 251, 261, 611 - 616, 651 - 653, 661 |
