神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-019) - CYLINDER ASSY, ARM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
302 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1323F1 | [1] | CYLINDER | KOBASSY, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U1323F2 |
| 1. | 2438U1323S1 | [1] | TUBE, CYLINDER ASSY | TUBE, CYLINDER ASSY |
| 2. | 2438U1323S2 | [1] | PISTON ROD | KOBASSY |
| 3. | 2438U1323S3 | [1] | CYLINDER HEAD | KOB |
| 4. | 2438U1323S4 | [1] | BUSHING | KOB |
| 5. | 2438U1323S5 | [1] | SNAP RING | KOB |
| 6. | 2438U1323S6 | [1] | RING | KOB |
| 7. | 2438U1323S7 | [1] | RING | RING |
| 8. | 2438U1323S8 | [1] | RING, BACK-UP | RING, BACK-UP |
| 9. | 2438U1323S9 | [1] | RING, WIPER | RING, WIPER |
| 10. | 2438U1323S10 | [1] | O-RING | O-RING |
| 11. | 2438U1323S11 | [1] | BACK-UP RING | KOB |
| 12. | 2438U1323S12 | [8] | SCREW | KOBSOCKET |
| 13. | 2438U1323S13 | [1] | BEARING | KOBCUSHION |
| 14. | 2438U1323S14 | [1] | PISTON | KOB |
| 15. | 2438U1323S15 | [1] | SEALING RING | KOBSEALRING ASSY |
| 16. | 2438U1323S16 | [2] | RING | KOB |
| 17. | 2438U1323S17 | [2] | RING | RING |
| 18. | 2438U1323S18 | [1] | NUT | KOB |
| 19. | 2438U1323S19 | [1] | SHIM | KOB |
| 20. | 2438U1323S20 | [1] | PIN | KOB |
| 21. | 2438U1323S21 | [1] | SNAP RING | KOB |
| 22. | 2438U1323S22 | [2] | BUSHING | KOB |
| 23. | 2438U1323S23 | [4] | WIPER BLADE | KOB Superseded by part number: 2445R138D8 |
| 24. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| . . | 2438U1323R100 | [1] | REPAIR KIT | KOBREPAIR, CONSISTS OF REF 6 - 11 |
| . . | 2438U1323R110 | [1] | REPAIR KIT | KOBREPAIR, CONSISTS OF REF 15 - 17 |
