神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-052) - VALVE ASSY, SOLENOID Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
949 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U989D0F1 | [1] | VALVE ASSY, SOLENOID, CONSISTS OF THE FOLLOWING PARTS | |
| 1. | 2436U989S1 | [1] | CASING | |
| 2. | 2436U989S2 | [1] | COVER | |
| 3. | 2436U989S3 | [1] | NAME-PLATE | |
| 4. | 2436U989S4 | [2] | SEAT | KOBSPRING |
| 5. | 2436U989S5 | [2] | SPRING, D1F1 - D4F1 | |
| 6. | 2436U989S6 | [1] | SPRING, D6F1 ONLY | |
| 7. | 2436U989S7 | [1] | SPRING, D5F1 ONLY | |
| 8. | 2436U989S8 | [2] | O-RING | KOB |
| 9. | 2436U989S9 | [4] | O-RING | KOB Superseded by part number: ZD12A01200 |
| 10. | 2436U989S10 | [4] | CAPSCREW | |
| 11. | 2436U989S11 | [4] | CAPSCREW | |
| 12. | 2436U989S12 | [4] | VIES | |
| 13. | 2436U989S13 | [1] | SOLENOID VALVE | KOB |
| 14. | 2436U989S14 | [1] | THROTTLE, D6F1 ONLY | |
| 15. | 2436U989S15 | [1] | SPOOL, D1F1 ONLY | |
| 16. | 2436U989S16 | [1] | SPOOL, D2F1 ONLY | |
| 17. | 2436U989S17 | [1] | SPOOL, D3F1 ONLY | |
| 18. | 2436U989S18 | [1] | SPOOL, D4F1 ONLY | |
| 19. | 2436U989S19 | [1] | SPOOL, D5F1 ONLY | |
| 20. | 2436U989S20 | [1] | SPOOL, D6F1 ONLY | |
| . . | 2436U989D100 | [1] | REPAIR KIT CONSISTS OF REF 8 & 9 | REPAIR KIT CONSISTS OF REF 8 & 9 |
| . . | 2445R273D1 | [1] | HYDRAULIC VALVE | KOBREPAIR, CONSISTS OF REF 8 & 13 |
| . . | 2436U989R110 | [1] | REPAIR KIT | KOBCONSISTS OF REF 8 & 25 |
