神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-054) - VALVE ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
603 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1272F1 | [1] | VALVE ASSY, CONSISTS OF THE FOLLOWING PARTS | |
| 201. | 2436U1272S201 | [1] | CASING | |
| 202. | 2436U1272S202 | [1] | CASING | |
| 251. | 2436U1807S251 | [11] | PLUG | PLUG |
| 252. | 2436U741S462 | [18] | PLUG | KOB |
| 261. | ZD12P01000 | [11] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 262. | ZD12P00800 | [17] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 2 63. | 2436U1272S263 | [1] | O-RING | O-RING |
| 271. | ZS23C08065 | [4] | CAP,Hex Socket Head, M8 x 65mm | KOBScrew -- M08x1.25x65mm |
| 272. | ZS23C08055 | [3] | CAPSCREW,Hex Socket Head, M8 x 55mm | KOBSCREW M08x1.25x55mm |
| 311. | 2436U1272S311 | [2] | SPOOL | |
| 312. | 2436U1272S312 | [1] | SPOOL | |
| 313. | 2436U1928S328 | [1] | PISTON | |
| 321. | 2436U1272S321 | [3] | SPRING | |
| 331. | 2436U1272S331 | [3] | SEAT, SPRING | |
| 511. | 2483U172S19 | [5] | BALL | KOB |
| 541. | 2436U1272S541 | [4] | SEAT | |
| 542. | 2436U1272S542 | [1] | SEAT | |
