| . . | 2437U214F1 | [1] | PUMP ASSY CONSISTS OF THE FOLLOWING PARTS | PUMP ASSY CONSISTS OF THE FOLLOWING PARTS |
| 11. | 2437U214S11 | [18] | PISTON | KOBCONSISTS OF REF 151 AND 152 |
| 13. | 2437U214S13 | [1] | CYLINDER | KOBCONSISTS OF REF 141 AND 313 Superseded by part number: 2437U214S13T |
| 14. | 2437U214S14 | [1] | CYLINDER | KOBCONSISTS OF REF 141 AND 314 Superseded by part number: 2437U214S14T |
| 30. | 2437U214S30 | [2] | PLATE | KOBCONSISTS OF REF 212 AND 214 |
| 530. | 2437U214S530 | [2] | PIN | KOBCONSISTS OF REF 531 AND 548 |
| (079). | 2436U1320F1 | [1] | VALVE | KOB |
| 111. | 2437U214S111 | [1] | SHAFT | KOBSEE FIG 11-019 |
| 113. | 2437U214S113 | [1] | SHAFT | KOB |
| 114. | 2437U214S114 | [1] | COUPLING | KOB |
| 123. | 2437U214S123 | [2] | BEARING | KOB Superseded by part number: 2441U474S123 |
| 124. | 2437U214S124 | [2] | NEEDLE BEARING | KOB Superseded by part number: 24100U992S2 |
| 127. | 2441U722S127 | [3] | SPACER | KOB |
| 141. | NSS | [2] | NOT SOLD SEPARAT | CONBLOCK CYLINDER |
| 151. | NSS | [18] | NOT SOLD SEPARAT | CONPISTON |
| 152. | NSS | [18] | NOT SOLD SEPARAT | CONSHOE |
| 153. | 2437U214S153 | [2] | PLATE | KOB |
| 156. | 2437U214S156 | [2] | BUSHING | KOB |
| 157. | 2437U214S157 | [18] | SPRING | KOB |
| 158. | 2437U214S158 | [2] | SPACER | KOB |
| 211. | 2441U564S124 | [2] | PLATE | KOB |
| 212. | NSS | [2] | NOT SOLD SEPARAT | CONPLATE |
| 214. | NSS | [2] | NOT SOLD SEPARAT | CONBUSHING |
| 251. | 2437U214S251 | [2] | COVER | KOB |
| 261. | 2437U214S261 | [1] | CUP COVER | KOB |
| 263. | 2437U214S263 | [1] | COVER | KOB |
| 271. | 2437U214S271 | [2] | HOUSING | KOBCASING |
| 312. | 2437U214S312 | [1] | BLOCK | KOB |
| 313. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE VALVE (R) |
| 314. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE VALVE (L) |
| 325. | 2437U213S325 | [1] | HOUSING | KOBCASING VALVE |
| 401. | 2437U214S401 | [8] | SCREW | KOB |
| 406. | ZS23C08020 | [8] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 407. | ZS23C06055 | [3] | CAPSCREW,Hex Socket Head, M6 x 55mm | KOBSCREW M06x1.0x55mm |
| 466. | 2441U722S466 | [3] | PLUG | KOB Superseded by part number: 2441U667S466 |
| 468. | 2441U722S469 | [3] | PLUG | KOB Superseded by part number: 2441U436S469 |
| 490. | 2441U722S490 | [32] | PLUG | KOB1/16" NPTF |
| 531. | NSS | [2] | NOT SOLD SEPARAT | CONLEVER |
| 532. | 2437U214S532 | [2] | PISTON | KOB |
| 534. | 2437U214S534 | [2] | STOP | KOB |
| 535. | 2437U214S535 | [2] | STOP | KOB |
| 541. | 2437U213S541 | [4] | SEAT | KOB Superseded by part number: 2437U219S41, 2437U219S42 |
| 542. | 2437U214S542 | [2] | SPACER | KOB |
| 543. | 2437U213S543 | [2] | STOPPER | STOPPER |
| 544. | 2437U213S544 | [2] | STOPPER | STOPPER |
| 545. | 2441U722S964 | [4] | BALL | KOB Superseded by part number: 2436U969S964 |
| 548. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
| 702. | ZD12G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 710. | ZD12G10500 | [2] | O-RING,104.40mm ID x 110.60mm OD x 3.10mm | KOBID 14.80 ± 0.20 x OD 19mm |
| 717. | 2441U741S472 | [2] | O-RING | KOB |
| 719. | 2441U413S719 | [2] | O-RING | KOB Superseded by part number: 2437U219S719 |
| 724. | ZD12P00800 | [16] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 726. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 728. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 732. | ZD12P02100 | [2] | O-RING,2.4mm Thk x 20.8mm ID, 90 Duro | KOBO-Ring -- ID 20.80 ± 0.23 x OD 25mm |
| 774. | 2437U214S774 | [1] | GASKET | KOB Superseded by part number: LC10V00010S019 |
| 789. | 2437U214S789 | [2] | BACK-UP RING | KOB Superseded by part number: 2437U471S789 |
| 792. | 2437U214S792 | [2] | RING, BACK UP | RING, BACK UP |
| 808. | ZN11C20012 | [4] | NUT | KOBM20x2.50mm |
| 824. | ZR16X04500 | [2] | RING | KOBRetaining -- ID 45 x OD 58 x Th 1.8mm |
| 885. | 2441U474S888 | [2] | PIN | KOB |
| 886. | ZP26D06014 | [4] | PIN | KOBRoll -- OD 06 x 14mm Long |
| 901. | 2441U413S902 | [2] | BOLT | KOB |
| 953. | 2437U214S953 | [2] | SCREW | KOB |
| 954. | 2437U214S954 | [2] | SET OF SCREWS | KOB |
| . . | 2437U214R100 | [1] | SEAL KIT | KOBCONSISTS OF REF 702, 710, 717, 719, 724-726, 728, 732, 774, 789, 792 Superseded by part number: 2437U214R200 |
