神钢零件查询(MD320BLC) - EXCAVATOR BTW YC0301 - YC0747 (1/80-12/06) (11-025) - CYLINDER ASSY, BOOM 2438U776 F1, F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
680 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U776F1 | [1] | BUCKET CYLINDER | KOBASSY, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U776F2 |
| . . | 2438U776F2 | [1] | CYLINDER | KOBASSY, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2438U776S1 | [1] | LINER, ENGINE CYLIND | KOB |
| 2. | 2438U776S2 | [1] | PISTON ROD | KOBROD ASSY, PISTON |
| 3. | 2438U776S3 | [1] | CYLINDER | KOBHEAD, CYLINDER |
| 4. | 2438U776S4 | [1] | BUSHING | KOB |
| 5. | 2438U776S5 | [1] | SNAP RING | KOB |
| 6. | 2438U776S6 | [1] | RING, BUFFER FOR F1 ONLY | RING, BUFFER FOR F1 ONLY |
| 7. | 2438U776S7 | [1] | RING | |
| 8. | 2438U776S8 | [1] | BACK-UP RING | KOB |
| 9. | 2438U776S9 | [1] | RING | KOB |
| 10. | ZD12P14000 | [1] | O-RING | KOB |
| 11. | 2438U1324S11 | [1] | BACK-UP RING | KOB |
| 12. | 2438U1323S12 | [8] | SCREW | KOB |
| 13. | 2438U776S13 | [1] | BUSHING, SPHERICAL | BUSHING, SPHERICAL |
| 14. | 2438U776S14 | [1] | PISTON | KOB |
| 15. | 2438U1324S15 | [1] | SEALING RING | KOB |
| 16. | 2438U1324S16 | [2] | RING | KOB |
| 17. | 2438U1324S17 | [2] | RING | KOB |
| 18. | 2438U776S18 | [1] | NUT | KOB |
| 19. | 2438U776S19 | [1] | SHIM | KOB |
| 20. | 2436U675S26 | [1] | PIN | PIN |
| 21. | 2436U675S27 | [1] | SNAP RING | KOB |
| 22. | 2438U776S22 | [1] | BUSHING | KOB |
| 23. | 2438U1323S23 | [2] | WIPER BLADE | KOB Superseded by part number: 2445R138D8 |
| 24. | 2438U776S24 | [1] | BUSHING | KOB |
| 25. | 2438U776S25 | [2] | SEAL,100mm ID x 120mm OD x 4mm Thk | KOB Superseded by part number: 2445R138D9 |
| 26. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 27. | 2438U1018S6 | [1] | RING | KOBFOR F2 ONLY |
| . . | 2438U776R10 | [1] | REPAIR KIT | KOBFOR F1 ONLY, CONSISTS OF REF 4-11, 15-17, 19, 23, 25 |
| . . | 2438U776R20 | [1] | REPAIR KIT, CONSISTS OF REF 1 AND 22 | |
| . . | 2438U776R30 | [1] | REPAIR KIT, CONSIST OF REF 2 AND 24 | |
| . . | 2438U776R40 | [1] | REPAIR KIT | KOBFOR F2 ONLY, CONSISTS OF REF 4, 5, 7-11, 25, 27 |
| . . | 2438U776R50 | [1] | REPAIR KIT | KOBREPAIR, FOR F2 ONLY, CONSISTS OF REF 15-17, 19, 23 |
| . . | 2438U776R100 | [1] | REPAIR KIT | KOBREPAIR, FOR F1 ONLY, CONSISTS OF REF 6-11 |
| . . | 2438U1324R110 | [1] | REPAIR KIT | KOBREPAIR, CONSISTS OF REF 15-17 |
| . . | 2438U776R200 | [1] | REPAIR KIT | KOBREPAIR, FOR F2 ONLY, CONSIST OF REF 7-11, 27 Superseded by part number: 2438U776R200P |
