神钢零件查询(MD320BLC) - EXCAVATOR BTW YC0301 - YC0747 (1/80-12/06) (11-026) - CYLINDER ASSY, ARM 2438U1323 F1, F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
240 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1323F1 | [1] | CYLINDER | KOBCYLINDER ASSY, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U1323F2 |
| . . | 2438U1323F2 | [1] | CYLINDER | KOBCYLINDER ASSY, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2438U1323S1 | [1] | TUBE, CYLINDER | TUBE, CYLINDER |
| 2. | 2438U1323S2 | [1] | PISTON ROD | KOB |
| 5. | 2438U1323S3 | [1] | CYLINDER HEAD | KOB |
| 4. | 2438U1323S4 | [1] | BUSHING | KOB |
| 5. | 2438U1323S5 | [1] | SNAP RING | KOB |
| 6. | 2438U1323S6 | [1] | RING | KOBFOR F1 ONLY |
| 7. | 2438U1323S7 | [1] | RING | RING |
| 8. | 2438U1323S8 | [1] | RING, BACK-UP | RING, BACK-UP |
| 9. | 2438U1323S9 | [1] | RING, WIPER | RING, WIPER |
| 10. | ZD12P15000 | [1] | O-RING | KOB |
| 11. | 2438U1323S11 | [1] | BACK-UP RING | KOB |
| 12. | 2438U1323S12 | [8] | SCREW | KOBBOLT, SOCKET |
| 13. | 2438U1395S13 | [1] | BEARING, CUSHION | BEARING, CUSHION |
| 14. | 2438U1323S14 | [1] | PISTON | KOB |
| 15. | 2438U1323S15 | [1] | SEALING RING | KOBSEALRING |
| 16. | 2438U1323S16 | [2] | RING | KOB |
| 17. | 2438U1323S17 | [2] | RING | RING |
| 18. | 2438U1323S18 | [1] | NUT | KOB |
| 19. | 2438U1323S19 | [1] | SHIM | KOB |
| 20. | 2438U1323S20 | [1] | PIN | KOB |
| 21. | 2438U1323S21 | [1] | SNAP RING | KOB |
| 22. | 2438U1323S22 | [2] | BUSHING | KOB |
| 23. | 2438U1323S23 | [4] | WIPER BLADE | KOB Superseded by part number: 2445R138D8 |
| 24. | NE82T04000 | [2] | PLUG | |
| 25. | 2438U1017S6 | [1] | RING, BUFFER FOR F2 ONLY | RING, BUFFER FOR F2 ONLY |
| . . | 2438U1323R10 | [1] | REPAIR KIT | KOBFOR F1 ONLY, CONSISTS OF REF 4-11, 15-17, 19 |
| . . | 2438U1323R20 | [1] | REPAIR KIT, CONSISTS OF REF 1 AND 22 | |
| . . | 2438U1323R30 | [1] | REPAIR KIT, CONSISTS OF REF 2 AND 22 | |
| . . | 2438U1323R40 | [1] | REPAIR KIT | KOBFOR F2 ONLY, CONSISTS OF REF 4, 5, 7-11, 25 |
| . . | 2438U1323R50 | [1] | REPAIR KIT | KOBFOR F2 ONLY, CONSISTS OF REF 15-17, 19, 23 |
| . . | 2438U1323R100 | [1] | REPAIR KIT | KOBFOR F1 ONLY, CONSISTS OF REF 6-11 |
| . . | 2438U1323R110 | [1] | REPAIR KIT | KOBCONSISTS OF REF 15-17 |
| . . | 2438U1323R200 | [1] | RIPPER | KOBREPAIR, FOR F2 ONLY, CONSISTS OF REF 1-11, 25 |
