神钢零件查询(MD320BLC) - EXCAVATOR BTW YC0301 - YC0747 (1/80-12/06) (11-027) - CYLINDER ASSY, BUCKET 2438U1324 F1, F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
349 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1324F1 | [1] | CYLINDER | KOBASSY, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U1324F2 |
| . . | 2438U1324F2 | [1] | CYLINDER | KOBASSY, BUCKET, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2438U1324S1 | [1] | TUBE | KOBASSY |
| 2. | 2438U1324S2 | [1] | PISTON ROD | KOB |
| 3. | 2438U778S3 | [1] | CYLINDER HEAD | KOB |
| 4. | 2438U1324S4 | [1] | BUSHING | KOB |
| 5. | 2438U1324S5 | [1] | SNAP RING | KOB |
| 6. | 2438U1324S6 | [1] | RING | KOBFOR F1 ONLY |
| 7. | 2438U1324S7 | [1] | O-RING | KOB |
| 8. | 2438U1324S8 | [1] | RING | KOBBACK UP |
| 9. | 2438U1324S9 | [1] | WIPER ARM | KOB Superseded by part number: 2438U1170S32 |
| 10. | ZD12P14000 | [1] | O-RING | KOB |
| 11. | 2438U1324S11 | [1] | BACK-UP RING | KOB |
| 12. | 2438U1323S12 | [8] | SCREW | KOBBOLT SOCKET |
| 13. | 2438U1324S13 | [1] | SPACER | KOBBEARING, CUSHION |
| 11. | 2438U1324S14 | [1] | PISTON | KOBPISTON |
| 15. | 2438U1324S15 | [1] | SEALING RING | KOBRING ASSY |
| 16. | 2438U1324S16 | [2] | RING | KOB |
| 17. | 2438U1324S17 | [2] | RING | KOBRING |
| 18. | 2438U1324S18 | [1] | NUT | KOB |
| 19. | 2438U1324S19 | [1] | SHIM | KOB |
| 20. | 2438U1324S20 | [1] | PIN | KOB |
| 21. | 2438U1324S21 | [1] | SNAP RING | KOB |
| 22. | 2438U1324S22 | [2] | BUSHING | KOB |
| 23. | 2438U1323S23 | [4] | WIPER BLADE | KOBRING WIPER Superseded by part number: 2445R138D8 |
| 24. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 25. | 2438U1324S25 | [1] | BACK-UP RING | KOBFOR F2 ONLY |
| . . | 2438U1324R10 | [1] | REPAIR KIT | KOBFOR F1 ONLY, CONSISTS OF REF 4-11, 15-17, 19 |
| . . | 2438U1324R20 | [1] | REPAIR KIT | KOBCONSISTS OF REF 1 AND 22 |
| . . | 2438U1324R30 | [1] | REPAIR KIT CONSISTS OF REF 2 AND 22 | REPAIR KIT CONSISTS OF REF 2 AND 22 |
| . . | 2438U1324R40 | [1] | SEAL KIT | KOBREPAIR, FOR F2 ONLY, CONSISTS OF REF 4, 5, 7-11, 25 |
| . . | 2438U1324R50 | [1] | REPAIR KIT | KOBFOR F2 ONLY, CONSISTS OF REF 15-17, 19, 23 |
| . . | 2438U1324R100 | [1] | SEAL KIT | KOBREPAIR, FOR F1 ONLY, CONSISTS OF REF 6-11 |
| . . | 2438U1324R110 | [1] | REPAIR KIT | KOBREPAIR, CONSISTS OF REF 15-17 |
| . . | 2438U1324R200 | [1] | REPAIR KIT | KOBREPAIR, FOR F2 ONLY, CONSISTS OF REF 7-11, 25 Superseded by part number: 2438U1324R200P |
