神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (01-002) - COUNTER-WEIGHT, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
985 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4077F2 | [1] | COUNTER-WEIGHT ASSY | |
| 2. | 2420T3031D4 | [3] | SCREW | KOB |
| 3. | R16T015207 | [3] | WASHER | |
| 4. | 2418T17697D1 | [1] | SPACER | KOB |
| 5. | 2418T17697D2 | [1] | SPACER | KOB |
| 6. | 2418T17697D3 | [1] | SPACER | KOB |
| 7. | 2420T5426 | [2] | BOLT | |
| 8. | ZN18C30024 | [2] | NUT | KOBM30x2.0mm |
| 9. | 2422J1825D2 | [1] | COUNTER-WEIGHT | |
| 9-35. | ZS18C20180 | [2] | SCREW,Hex, M20 x 180mm | KOBM20x2.5x180mm |
| 9-36. | ZW16H20000 | [2] | WASHER | KOBID 21 x OD 40 x Th 4.5mm |
