神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (01-007) - TANK ASSY, HYDR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
142 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J8862F1 | [1] | TANK ASSY, HYDR | |
| 1. | 2427J2079 | [1] | TANK | KOBHYDR |
| 2. | 2440N178 | [1] | MANIFOLD | |
| 3. | 2446R146F7 | [1] | STRAINER ELEMENT | KOB |
| 3-1. | 2446R146S1 | [1] | STRAINER ELEMENT | KOB Superseded by part number: 2446U173 |
| 3-2. | 2446R146S2 | [1] | HOLDER GUIDE | HOLDER GUIDE |
| 3-4. | 2446R146S4 | [2] | NUT | |
| 3-5. | 2446R146S5 | [1] | SPRING | SPRING |
| 3-6. | 2446R146S6 | [1] | O-RING | KOB |
| 3-12. | 2446R146S12 | [1] | BOLT, CENTER | |
| 4. | 2446U214Fl | [1] | FILTER, DRAIN | |
| 4-3. | 2446U141S2 | [1] | SPARE PART | HIT Superseded by part number: S15510-20200 |
| 5. | R36P0002 | [2] | ELEMENT | KOB Superseded by part number: YN50V00001P1 |
| 6. | 2418N2805 | [1] | PIPE | |
| 7. | 2446R131 | [2] | VALVE | KOBRELIEF |
| 8. | 241BZ951 | [1] | COUPLING | |
| 9. | 24R9R173F1 | [1] | GAUGE, LEVEL | |
| 9-1. | 2489R173S1 | [1] | GAUGE | KOB |
| 9-2. | 2489R173S2 | [2] | BOLT | BOLT |
| 9-3. | 24R9R173S3 | [2] | BLOCK | |
| 9-4. | ZD11P01800 | [2] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 9-5. | ZD11P01400 | [4] | O-RING | KOBID 13.8 ± 0.19 x OD 18.6mm |
| 10. | 2418T4625D2 | [2] | FLANGE | |
| 11. | R44P0012D1 | [1] | COCK, DRAIN | COCK, DRAIN |
| 12. | 2417T296 | [2] | SPRING | KOB |
| 13. | 2436Z274D4 | [1] | VALVE PRESSURE RELIE | KOB |
| 14. | ZD11G22000 | [2] | O-RING,5.7mm Thk x 219.3mm ID, 70 Duro | KOBO-Ring -- ID 219.30 ± 1.68 x OD 222.66mm |
| 15. | ZD11G19000 | [2] | O-RING,189.30mm ID x 200.70mm OD x 5.70mm | KOBID 189.30 ± 1.47 x OD 200mm |
| 16. | 2440P311 | [1] | MANIFOLD | |
| 17. | ZX21M12060 | [1] | HOSE | KOB600mm Long (23-5/8in) |
| 19. | 2444Z2742 | [1] | TEE | TEE |
| 20. | ZE72X12000 | [1] | PLUG | KOB(3/4" PF) (Incls. O-Ring ZD12P02400) |
| 21. | ZH32X12016 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 1", O-Ring | KOB |
| 22. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 22-1. | ZD12P02240 | [1] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 23. | ZS18C16035 | [8] | SCREW,Hex, M16 x 35mm | KOBM16x2.0x35mm |
| 25. | ZS18C10025 | [24] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 26. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 28. | ZW26X10000 | [26] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 29. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 30. | ZW16H16000 | [8] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 31. | B16T0187D1 | [2] | SHIM, 1.6 | SHIM, 1.6 |
| 32. | B16T0187D2 | [2] | SHIM, 2.3 | SHIM, 2.3 |
| 34. | 2418T5373C2 | [2] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 35. | ZS18CJ0020 | [2] | CAPSCREW | |
| 37. | 2418P14151 | [1] | PIPE | PIPE |
| 40. | 2418T6879 | [1] | PLATE | HIT |
| . . | 24046Z18 | [1] | ELEMENT | KOBKIT, ELEMENT CONSISTS OF ITEM 5, 15 Superseded by part number: YN50V00004F2 |
