神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (01-008) - TANK ASSY, FUEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
262 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J7670F3 | [1] | TANK ASSY, FUEL | |
| 4. | R36T0006 | [1] | STRAINER ELEMENT | KOB |
| 5. | 2489U167F1 | [1] | SENDER UNIT | KOB |
| 6. | 2416P3815 | [1] | COVER | |
| 7. | 2436R241F1 | [1] | COCK | KOB Superseded by part number: LC20P01028P1 |
| 7-2. | B14N0094E14 | [1] | PACKING | KOB |
| 8. | ZE82T08000 | [1] | PLUG | KOB1/2" PT |
| 9. | 2432Z30901 | [4] | CLAMP | |
| 11. | ZW26X16000 | [4] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 12. | ZW16M16000 | [4] | WASHER | |
| 13. | B16T0187D8 | [2] | SHIM | |
| 14. | B14T0187D7 | [2] | SHIM | |
| 15. | 2418T9962 | [1] | PACKING | KOBID 41 x OD 68 x Th 2.0mm |
| 16. | ZW16K05000 | [5] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 17. | ZS31C05025 | [5] | SCREW,Phillips Drive, Pan HD, M5 x 25mm | KOBM05x0.8x25mm |
| 18. | ZW26X03000 | [5] | LOCK WASHER | HIT |
| 19. | 2427J1893D2 | [1] | TANK, FUEL | TANK, FUEL |
| 20. | 2489R237F2 | [1] | GAUGE | KOB |
| 20-2. | 2489R174S2 | [2] | BLOCK | KOBGAUGE, LEVEL |
| 20-3. | 2489R174S3 | [2] | BOLT | KOBSpecial -- M10x1.50x40mm Long |
| 20-4. | ZD11P01000 | [4] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 20-5. | ZD11P18000 | [4] | O-RING | KOB |
| 20-6. | 2489R174S7 | [1] | FLOAT | KOB |
| 20-7. | 2489R236D2 | [1] | LEVEL GAUGE | KOB |
| 21. | 2446R310 | [1] | FILLER CAP | KOBFILLER |
| 22. | ZC15X01500 | [1] | CLIP | KOB |
| 23. | 2420Z899D3 | [1] | HOSE | KOB |
| 24. | ZS18C16040 | [4] | SCREW,Hex, M16 x 40mm | KOBM16x2.0x40mm |
| 25. | 2414T2861D3 | [1] | GUARD | GUARD |
