神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-040) - VALVE ASSY/ P.N. 2436U851F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
982 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U851F1 | [1] | VALVE ASSY CONSITS OF THE FOLLOWING PARTS | |
| 1. | 2436U1851S1 | [1] | BODY | |
| 2. | 2436U1851S2 | [1] | SCREW, ADJUST | |
| 3. | 2441U399S84 | [2] | FILTER | FILTER |
| 4. | ZS23C06065 | [4] | SCREW,Hex Socket Head, M6 x 65mm | KOBM06x1.0x65mm |
| 5. | ZW22K06000 | [4] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 6. | 2436U1695S15 | [3] | O-RING | KOB |
| 7. | 2436U1691S34 | [1] | ORIFICE | ORIFICE |
| 8. | 2436U1691S30 | [2] | PLUG | |
| 9. | 2436U1691S31 | [1] | PLUG | |
| 10. | 2436U1691S33 | [2] | PLUG | KOB |
| 11. | 2436U1695S12 | [1] | NUT | |
| 12. | 2436U1851S12 | [1] | CAP | |
