神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (03-004) - PUMP ASSY, GREASE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
556 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2421U10F2 | [1] | PUMP ASSY GREASE YS. 0101 to YS. 0142 | PUMP ASSY GREASE YS. 0101 to YS. 0142 |
| . . | 2421U10F3 | [1] | PUMP | KOBGREASE YS., Start Serial: 0143 Superseded by part number: 2421U10F4 |
| 1. | 2421U10S1 | [1] | RIGID TUBE | KOB |
| 2. | 2421U10S2 | [1] | BODY | KOBYS. 0101 to YS. 0142 |
| 3. | ZW22X06000 | [4] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 4. | 2421U10S4 | [1] | COVER YS. 0101 to YS. 0142 | |
| 5. | 2421U10S5 | [3] | SCREW | KOBCAPSCREW |
| 6. | 2421U10S6 | [1] | PLATE | KOBYS. 0101 to YS. 0142 |
| 7. | 2421U10S7 | [1] | TUBE YS. 0101 to YS. 0142 | |
| 8. | ZS31C06010 | [4] | SCREW,Phillips Drive, Pan HD, M6 x 10mm | KOBM06x1.0x10mm |
| 9. | 2421U10S9 | [1] | GREASE GUN | KOB |
| 10. | 2421U10S10 | [1] | PUMP, Serial Range: YS.0101-YS.0142 | PUMP, Serial Range: YS.0101-YS.0142 |
| 1 1. | 2421U10S11 | [2] | HANDLE | |
| 12. | 2421U10S12 | [4] | NUT | |
| 13. | 2421U10S13 | [1] | SUPPORT | |
| 14. | 2421U10S14 | [1] | WASHER | |
| 15. | ZS31C06014 | [1] | SCREW,Phillips Drive, Pan HD, M6 x 14mm | KOBM06x1.0x14mm |
| 16. | 2421U10S16 | [1] | HYDRAULIC VALVE | KOB |
| 17. | 2421U10S17 | [1] | CAP | CAP |
| 18. | 2421U10S18 | [1] | LABEL | |
| 19. | 2421U10S19 | [1] | ADAPTER YS. 0101 to YS. 0142 | |
| 20. | 2421U10S20 | [1] | BODY YS., Start Serial: 0143 | |
| 21. | 2421U10S21 | [1] | COVER YS., Start Serial: 0143 | |
| 22. | 2421U10S22 | [1] | PLATE | KOBYS., Start Serial: 0143 |
| 23. | 2421U10S23 | [1] | HYDRAULIC PUMP | KOBYS., Start Serial: 0143 |
| 24. | 2421U10S24 | [1] | WASHER | KOBWASHER YS., Start Serial: 0143 |
| 25. | 2421U10S25 | [1] | BUSHING | KOBBUSHING YS., Start Serial: 0143 |
| 26. | 2421U10S26 | [1] | ELBOW UNION | KOBUnion Elbow ADAPTER YS., Start Serial: 0143 |
