神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (04-001) - HYDR LINES, UPP/ P.N. 24100X1368F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
307 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X1368F1 | [1] | HYD LINES, UPP | |
| 1. | 2418N4539 | [1] | TUBE | TUBE |
| 2. | 2418T15727D2 | [1] | TUBE | TUBE |
| 3. | 2418P17308 | [1] | TUBE | KOB |
| 4. | 2418T15728 | [1] | TUBE | TUBE |
| 5. | 2418P17310D2 | [1] | TUBE | TUBE |
| 6. | 2418N2895 | [1] | TUBE | TUBE |
| 7. | 2418P17309D2 | [1] | TUBE | |
| 8. | 2436R394F2 | [1] | CHECK VALVE | KOB |
| 8-1. | 2436R394S1 | [1] | CASE | |
| 8-2. | 2436R394S2 | [1] | CAPSCREW | |
| 8-3. | R45T0004D2 | [1] | WASHER, SEAL | WASHER, SEAL |
| 8-5. | 2436R394S5 | [1] | VALVE ASSY N/A | VALVE ASSY N/A |
| 9. | 2420R367D7 | [2] | FLEXIBLE HOSE | KOB |
| 10. | 2416T18073 | [1] | BRACKET | |
| 1 1. | 2416T11964 | [1] | BRACKET BRACKET | BRACKET BRACKET |
| 12. | 2416T18074 | [1] | BRACKET | |
| 13. | 2432T1203 | [2] | CLAMP | CLAMP |
| 14. | 2432T3013 | [1] | CLAMP | KOB |
| 15. | 2432T1588 | [4] | CLAMP | KOB |
| 16. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 17. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 18. | ZD12P04400 | [2] | O-RING | KOB |
| 19. | ZG15F04500 | [5] | COUPLING | KOB |
| 20. | ZG15F03800 | [1] | COUPLING | KOB |
| 21. | 2432R182D10 | [8] | CLAMP | KOB |
| 22. | 2420T2948D5 | [1] | U-BOLT | KOBM08x1.25x ID 45 x 80.5mm Long |
| 23. | 2420T5801D1 | [2] | SHIM | |
| 24. | 2420T5801D2 | [2] | SHIM | |
| 25. | 2418T15342 | [2] | SPACER | |
| 26. | ZW26X12000 | [3] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 27. | ZW26X10000 | [9] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 28. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 29. | ZW26K12000 | [12] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 30. | ZW16X12000 | [6] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 31. | ZW16X10000 | [9] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 32. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 33. | 2418T5373C2 | [2] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 34. | 2420N458D12035 | [8] | SCREW,Hex Socket Head, M12 x 35mm | KOB Superseded by part number: ZS28C12035 |
| 35. | 2420N458D12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBCAPSCREW Superseded by part number: ZS28C12030 |
| 36. | ZS18C10055 | [2] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 37. | ZS18C10030 | [5] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 38. | ZS18C12085 | [2] | SCREW,Hex, M12 x 85mm | KOBM12x1.75x85mm |
| 39. | ZS18C12075 | [1] | SCREW,Hex, M12 x 75mm | KOBM12x1.75x75mm |
| 41. | ZS18C10040 | [2] | SCREW,Hex, M10 x 40mm | KOBM10x1.50x40mm |
| 42. | ZN18C12010 | [3] | NUT | KOBM12x1.75mm |
| 43. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 44. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 45. | 2420Z804 | [2] | LOCK NUT | KOB |
