神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (04-003) - HYDR LINES, UPP/ P.N. 24100X1369F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
992 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X1370F1 | [1] | HYDR LINES, UPP | |
| 1. | 2418P12390 | [1] | TUBE | KOB |
| 2. | 2418P12391 | [1] | TUBE | KOB |
| 3. | 2418P17294 | [1] | TUBE | TUBE |
| 4. | 2418P17295 | [1] | TUBE | TUBE |
| 5. | 2418P12392 | [1] | TUBE | KOB |
| 6. | 2418P12394 | [1] | TUBE | |
| 7. | 2418P17298 | [1] | TUBE | TUBE |
| 8. | 2418P12397 | [1] | TUBE | KOB |
| 9. | 2418P19372 | [1] | TUBE | KOB |
| 10. | 2418P12393 | [1] | TUBE | |
| 11. | 2418N4540 | [1] | TUBE | |
| 12. | 2418P9058 | [1] | TUBE | KOB |
| 14. | 2418P10897 | [1] | TUBE | KOB |
| 15. | 2418N2506 | [1] | TUBE | TUBE |
| 16. | 2418N2507 | [1] | TUBE | KOB |
| 17. | 2418P10913D1 | [2] | TUBE | TUBE |
| 18. | 2418P10913D2 | [2] | TUBE | TUBE |
| 19. | 2444R1439D1 | [1] | HOSE | KOB |
| 20. | ZX28S16070 | [2] | HOSE | KOB |
| 21. | ZX28S16080 | [1] | HOSE | KOB |
| 22. | ZX28S16090 | [1] | HOSE | KOB |
| 23. | 24100P832F1 | [1] | VALVE, CHECK | |
| 23-1. | 2414P2390 | [1] | CASE | |
| 23-2. | 2436T213 | [1] | POPPET | |
| 23-5. | 2418P7099D2 | [1] | PLATE | |
| 23-6. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 24. | 24100P832F4 | [1] | CHECK VALVE | KOB |
| 24-1. | 2414P2390 | [1] | CASE | |
| 24-3. | 2436T214D5 | [1] | POPPET | |
| 24-5. | 2418P7099D2 | [1] | PLATE | |
| 24-6. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 25. | 24100P832F3 | [1] | CHECK VALVE | KOB |
| 25-1. | 2414P2390 | [1] | CASE | |
| 25-4. | 2436T214D2 | [1] | POPPET | |
| 25-5. | 2418P7099D2 | [1] | PLATE | |
| 25-6. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 26. | 2416P8036 | [1] | BLOCK | BLOCK |
| 27. | ZD12P03400 | [20] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 28. | ZD12P02900 | [5] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 29. | ZF23B35000 | [2] | HYD CONNECTOR | KOB |
| 30. | ZF53B35000 | [2] | HYD CONNECTOR | KOB |
| 31. | ZE13X16000 | [32] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 32. | 2416T12005D1 | [1] | BRACKET | BRACKET |
| 33. | 2416T12005D2 | [1] | BRACKET | KOB |
| 34. | 2416T17180 | [1] | BRACKET | |
| 35. | 2432T2143D1 | [2] | CLAMP | CLAMP |
| 36. | 2432T2143D2 | [2] | CLAMP | CLAMP |
| 37. | ZC36X35016 | [4] | CLAMP | KOB |
| 39. | 2420N458D12120 | [8] | SCREW,Hex Socket Head, M12 x 120mm | KOB Superseded by part number: ZS28C12120 |
| 40. | 2420N458D12150 | [4] | CAPSCREW | |
| 41. | ZS18C12025 | [4] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 42. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 43. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 44. | ZS18C12070 | [4] | SCREW,Hex, M12 x 70mm | KOBM12x1.75x70mm |
| 45. | ZS18C12050 | [6] | SCREW,Hex, M12 x 50mm | KOBM12x1.75x50mm |
| 46. | ZW26X12000 | [16] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 47. | ZW26K12000 | [68] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 48. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 49. | 2418T5373C2 | [4] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 50. | ZW16X12000 | [8] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 51. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| 52. | 2444T1342 | [1] | HYD CONNECTOR | KOB |
| 53. | 2414Z199D30 | [4] | PROTECTIVE SLEEVE | KOBHose -- 300mm Long (11-13/16 in), NOT SHOWN Superseded by part number: 2414Z199D030 |
