神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (04-004) - AIR-LINES, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
481 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X2107F1 | [1] | AIR-LINES, UPP | |
| 1. | R38N0012 | [1] | RESERVOIR | KOB |
| 2. | 2446U156F1 | [1] | VALVE PRESSURE RELIE | KOBVALVE, REDUCTION |
| 2-21. | 2446U133521 | [1] | ELEMENT | |
| 2-22. | 2446U133522 | [1] | O-RING | |
| 2-30. | 2446U196530 | [1] | BOWL | |
| 3. | 2447U2 | [1] | HORN | KOB Superseded by part number: 2447U46 |
| 4. | R38N0014 | [1] | KIT DIA, CRAWLER EXC | KOB |
| 6. | R38T0001D4 | [1] | VALVE PRESSURE RELIE | KOB |
| 7. | R38T0014 | [2] | VALVE | KOB |
| 8. | 2418T9562 | [1] | TUBE | KOB |
| 9. | ZX15K08040 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 10. | ZX15K08065 | [1] | TUBE | KOB |
| 11. | ZX15K08030 | [1] | FLEXIBLE HOSE | KOB |
| 12. | ZX15K04130 | [1] | TUBE, NYLON | TUBE, NYLON |
| 13. | 2479U497 | [1] | SENDER UNIT | KOB |
| 14. | ZX15K04330 | [1] | TUBE | KOB |
| 15. | ZX15K04080 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 17. | 2444Z1624D3 | [1] | HOSE | HOSE |
| 18. | 2420Z809 | [1] | HOSE | KOB |
| 19. | 2436R339 | [2] | COCK, DRAIN | KOB |
| 20. | B20T0041 | [2] | U-BOLT | KOB |
| 21. | ZC15X01500 | [3] | CLIP | KOB |
| 22. | 2418P9093 | [1] | TUBE | KOB |
| 23. | ZG81U04000 | [1] | CROSS | CROSS |
| 24. | ZG51U04000 | [2] | TEE | KOB |
| 25. | ZG21B04002 | [1] | GASKET | KOBBUSHING |
| 26. | ZG21E04000 | [6] | HYD CONNECTOR | KOB |
| 27. | ZH31K08006 | [1] | ELBOW | KOB |
| 28. | ZH31K08004 | [3] | ELBOW | KOB |
| 29. | ZH31K04002 | [1] | ELBOW | KOB |
| 30. | ZH21K08004 | [2] | HYD CONNECTOR | KOB |
| 31. | ZH21K04004 | [5] | HYD CONNECTOR | KOB |
| 32. | ZG21U04000 | [2] | SOCKET | KOBELBOW |
| 33. | R44P0046D3 | [1] | ELBOW | KOB |
| 34. | R44P0045D2 | [1] | PLUG | KOB |
| 39. | 2444T1393 | [1] | CONNECTOR | CONNECTOR |
| 36. | R44T0198 | [1] | CONNECTOR | CONNECTOR |
| 37. | 2444T1169 | [2] | HYD CONNECTOR | KOB |
| 38. | 2444T1170 | [1] | HYD CONNECTOR | KOB |
| 39. | 2444Z1293D6 | [1] | LUBE NIPPLE | KOBNipple, Hose -- 1/4"PTx39mm Long |
| 40. | 2444Z1293D7 | [1] | CONNECTOR Nipple, Hose -- 1/4\"PTx40mm Long | CONNECTOR Nipple, Hose -- 1/4"PTx40mm Long |
| 41. | ZC45X12011 | [6] | CLIP | CLIP |
| 42. | 2432Z290D2 | [9] | CLIP | KOBWire Ties -- 100mm Long Superseded by part number: YT50C01100P1 |
| 43. | ZS18C08035 | [2] | SCREW,Hex, M8 x 35mm | KOBM08x1.25x35mm |
| 44. | ZS18C08012 | [2] | SCREW,Hex, M8 x 12mm | KOBM08x1.25x12mm |
| 45. | ZM11C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 46. | ZM11C06012 | [2] | SCREW | KOB |
| 47. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 48. | ZW16X08000 | [14] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 49. | ZW16X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 50. | ZW26X08000 | [10] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 51. | ZN18C08007 | [10] | NUT | KOBM08x1.25mm |
| 52. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 55. | ZG21E06004 | [1] | CONNECTOR NIPPLE | CONNECTOR NIPPLE |
| 56. | ZG31B04000 | [1] | ELBOW | ELBOW |
| 59. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 60. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 61. | 2421U10F2 | [1] | PUMP ASSY SEE FIGURE 03-003 YS. 0101 to YS. 0142 | PUMP ASSY SEE FIGURE 03-003 YS. 0101 to YS. 0142 |
| . . | 2421U10F3 | [1] | PUMP | KOBSEE FIGURE 03-003 YS., Start Serial: 0143 Superseded by part number: 2421U10F4 |
| 62. | 2486U24F1 | [1] | HOSE REEL ASSY | |
| 63. | ZS18C08016 | [6] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 5. | MC802148 | [1] | GOVERNOR ( MITSUBISHI PARTS. NO.) | |
| 16. | MH032863 | [1] | HOSE ( MITSUBISHI PARTS. NO.) | |
| 53. | MH035107 | [4] | GASKET ( MITSUBISHI PARTS. NO.) | |
| 54. | MF660063 | [1] | GASKET | SUM( MITSUBISHI PARTS. NO.) Superseded by part number: 132342A1 |
