神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (05-006) - SUB-TANK ASSY, RADIATOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
679 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N3847F1 | [1] | TANK | KOBRADIATOR |
| 1. | 2427U407F1 | [1] | CONTAINER | KOB |
| 1-1. | 2427U407S1 | [1] | CONTAINER | KOB |
| 1-2. | 2427U407S2 | [1] | CAP | KOB |
| 1-3. | 2427U407S3 | [1] | CAP | KOB |
| 1-4. | 2427U203S5 | [1] | SWITCH | KOB |
| 1-5. | 2427U203S3 | [1] | LABEL | KOB |
| 2. | 2416P11159 | [1] | BRACKET | |
| 3. | 2416P10973 | [1] | BRACKET | BRACKET |
| 4. | 2416T17287 | [1] | SUPPORT | |
| 5. | 24202912D3 | [1] | HOSE | |
| 6. | 2418R146D3 | [1] | HOSE | HOSE |
| 7. | ZC15X01300 | [2] | CLIP | KOB |
| 8. | ZC15X01000 | [1] | CLIP | KOB |
| 10. | 2418T5373C2 | [2] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 11. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 12. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 13. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 14. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 15. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 16. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 17. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 18. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
