神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (05-007) - CONTROL ASSY, ENGINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
466 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J7736F2 | [1] | CONTROL ASSY, ENGINE | |
| 2. | 2416P10316D2 | [1] | BRACKET | |
| 3. | 2416T15694 | [1] | BRACKET | KOB |
| 5. | 2406T2249D2 | [1] | LEVER | |
| 7. | 2406T2281 | [1] | LEVER | KOB |
| 9. | 2419T3314 | [4] | PIN | KOB |
| 10. | ZS18C08035 | [2] | SCREW,Hex, M8 x 35mm | KOBM08x1.25x35mm |
| 11. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 12. | ZS18C06014 | [2] | SCREW,Hex, M6 x 14mm | KOBM06x1.0x14mm |
| 13. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 14. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 15. | ZP16K01610 | [4] | SPLIT PIN | KOBCotter |
| 18. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 21. | 2406T2426 | [1] | LEVER | |
