神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (06-007) - REDUCTION UNIT/ P.N. 24100X1998F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
286 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100XI998F2 | [1] | REDUCTION UNIT | |
| 2. | 2418J344 | [1] | HUB | HUB |
| 3. | ZD57F34040 | [1] | FLOAT | KOB Superseded by part number: ZD58F34040 |
| 4. | 2418N2014 | [1] | RETAINER | KOB |
| 5. | 2425R200 | [2] | BEARING | KOB |
| 6. | 2414J1387F1 | [1] | COVER ASSY | COVER ASSY |
| 6-1. | 2414J1386 | [1] | COVER | COVER |
| 6-2. | 2401P587 | [1] | RING GEAR | KOB |
| 6-3. | 419P0009D103 | [8] | PIN | |
| 7. | 2418P8839 | [1] | COUPLING | KOB |
| 8. | 2401N498 | [1] | GEAR, RING | GEAR, RING |
| 9. | 2418P13447 | [1] | WASHER, THRUST | |
| 10. | 2418T9392 | [1] | INSULATOR | KOB |
| 11. | 2418P12837 | [1] | THRUST WASHER | KOB |
| 12. | 2401N499 | [1] | SUN GEAR | KOB |
| 13. | 2401P896 | [1] | SUN GEAR | KOB |
| 14. | 2401P583 | [1] | GEAR, SUN | GEAR, SUN |
| 15. | 2413J476 | [1] | SPIDER | KOB |
| 16. | 2413J293 | [1] | AIR COMPRESSOR | AIR COMPRESSOR |
| 17. | 2413N561F1 | [1] | SPIDER | KOB |
| 17-1. | 2413N361 | [1] | SPIDER | |
| 17-2. | 2410P696 | [3] | SHAFT | |
| 18. | 2444Z1137D5 | [2] | PLUG | PLUG |
| 19. | 2418T13629 | [1] | BUTTON | KOB |
| 20. | ZR26X03800 | [1] | SNAP RING | KOB |
| 21. | ZR16X03000 | [3] | SNAP RING | KOB |
| 22. | 2401P384 | [3] | PINION, PLANETARY | |
| 23. | 2401P385 | [3] | GEAR, SUN PINION, PLANETARY | GEAR, SUN PINION, PLANETARY |
| 24. | 2401P586 | [4] | PINION | KOB |
| 25. | 2418P13444 | [1] | RETAINER | RETAINER |
| 26. | 2418T9394 | [7] | PLATE | KOB |
| 27. | 2418T9478 | [8] | LOCKING PLATE | KOB |
| 28. | ZS23C06014 | [8] | CAPSCREW M06x1.0x14mm | CAPSCREW M06x1.0x14mm |
| 29. | 2410P697 | [8] | SHAFT | KOB |
| 30. | 2410P698 | [4] | SHAFT | KOB |
| 31. | 2418T5454 | [8] | THRUST WASHER | KOB |
| 32. | 2418T9390 | [6] | THRUST WASHER | KOB |
| 33. | 2418T5414 | [6] | THRUST WASHER | KOB |
| 34. | ZS23C10025 | [18] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm Superseded by part number: ZS28C10025 |
| 35. | ZS23C20055 | [24] | SCREW,Hex Socket Head, M20 x 55mm | KOBM20x2.5x55mm |
| 36. | ZS23C08016 | [8] | SCREW,Hex Socket Head, M8 x 16mm | KOBM08x1.25x16mm |
| 37. | ZS23C12040 | [20] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 38. | ZS23C08014 | [6] | SCREW,Hex Socket Head, M8 x 14mm | KOBM08x1.25x14mm |
| 39. | ZS23C12030 | [18] | SCREW,Hex Socket Head, M12 x 30mm | KOBM12x1.75x30mm |
| 40. | 2420T473401 | [1] | SHIM | |
| 41. | 2420T473402 | [1] | SHIM | |
| 42. | 2420T4734D3 | [1] | SHIM | KOB |
| 43. | 2420T4734D4 | [1] | SHIM | KOB |
| 44. | 2420T4734D5 | [1] | SHIM | KOB |
| 45. | 2420T4734D6 | [1] | SHIM | KOB |
| 46. | 2420T4734D7 | [1] | SHIM | KOB |
| 48. | 2420T4734D8 | [1] | SHIM | KOB |
| 49. | 2420T473D10 | [1] | SHIM | |
| 50. | 2420T5341D1 | [1] | SHIM | KOB |
| 51. | 2420T5341D2 | [3] | SHIM | KOB |
| 52. | ZS23C10020 | [4] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
| 53. | ZS83C12035 | [2] | SCREW | KOB |
| 54. | 2410J367 | [1] | SPINDLE | SPINDLE |
