神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (06-010) - HYDR LINES, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
926 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6531F1 | [1] | HYD LINES, UPP | |
| 1. | 2418N4553D1 | [1] | TUBE | TUBE |
| 2. | 2418N4553D2 | [1] | TUBE | KOB |
| 3. | 2418N4552D1 | [1] | TUBE | TUBE |
| 4. | 2418N4552D2 | [1] | TUBE | KOB |
| 5. | 2418N4550D1 | [1] | TUBE | KOB |
| 6. | 2418N4550D2 | [1] | TUBE | KOB |
| 7. | 2418N4551D1 | [1] | TUBE | TUBE |
| 8. | 2418N4551D2 | [1] | TUBE | KOB |
| 9. | 2418P14594D1 | [1] | TUBE | KOB |
| 10. | 2418P14594D2 | [1] | TUBE | KOB |
| 11. | 2418P14593 | [1] | TUBE | KOB |
| 12. | 2418P14591 | [2] | TUBE | KOB |
| 13. | 2418P14592D1 | [1] | TUBE | KOB |
| 14. | 2418P14592D2 | [1] | TUBE | KOB |
| 15. | ZF23B10000 | [2] | CONNECTOR | CONNECTOR |
| 16. | ZF23835000 | [4] | CONNECTOR | |
| 17. | ZF23F22012 | [1] | HYD CONNECTOR | KOB |
| 19. | ZF23F10004 | [4] | HYD CONNECTOR | KOB |
| 20. | ZF23F22008 | [2] | TOOL | KOB |
| 21. | ZF53B22000 | [1] | TEE | KOB |
| 22. | ZE13X16000 | [16] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 23. | ZD12P03400 | [8] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 24. | ZD12P01100 | [4] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 25. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 26. | ZD12P02240 | [1] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 27. | ZS23C12040 | [32] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 28. | ZW26K12000 | [32] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 29. | 2432T1921 | [4] | CLAMP | CLAMP |
| 30. | ZC37X35114 | [4] | CLAMP | KOB |
| 31. | ZC27X22012 | [2] | COLLAR | HIT |
| 32. | ZC27X10009 | [2] | CLAMP | CLAMP |
| 33. | ZS18C12065 | [2] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 34. | ZS18C12045 | [2] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| 35. | ZS18C10055 | [2] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 36. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 37. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 38. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 39. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 40. | ZW26X12000 | [10] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 41. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 42. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 43. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| 44. | ZW16X12000 | [8] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 46. | 2416T10509 | [2] | BRACKET | BRACKET |
| 47. | 2416P10166 | [2] | BRACKET | BRACKET |
