| . . | 24100J7711F1 | [1] | ARM ASSY, 11"-2" | |
| 1. | 2411X934F1 | [1] | ARM | |
| 1-30. | 2405T919 | [2] | BUSHING | KOB |
| 1-31. | 2405P307 | [2] | BUSHING | KOBID 100 x OD 120 x 110mm Long, Flange OD 190 Superseded by part number: 2405P311 |
| 1-32. | 2405T420 | [2] | BUSHING | |
| 1-33. | 2418T9359 | [1] | SPACER | KOB |
| 1-35. | 2418T9360D1 | [1] | SPACER | KOBID 108 x OD 119.9 x 220mm Long |
| 1-34. | 2445N138D13 | [2] | SEAL | |
| 1-37. | 2445R138D9 | [2] | SEAL,100mm ID x 120mm OD x 4mm Thk | KOBDust -- ID 100 x OD 120 x Th 4mm |
| 2. | 2438U664F1 | [1] | BRACKET | KOB |
| 3. | 2406N1042D1 | [1] | LINK, IDLER | LINK, IDLER |
| 4. | 2406N1042D2 | [1] | LINK, IDLER | LINK, IDLER |
| 5. | 2406N1037F1 | [1] | LINK, BUCKET | LINK, BUCKET |
| 5-1. | 2406N1037 | [1] | LINK, BUCKET | |
| 5-7. | 2405P311 | [2] | BUSHING | KOBID 100 x OD 120 x 110mm Long, Flange OD 190 |
| 5-8. | 2405T921 | [2] | BUSHING | KOBID 100 x OD 120 x 108mm Long |
| 5-10. | 2445R138D9 | [4] | SEAL,100mm ID x 120mm OD x 4mm Thk | KOBDust -- ID 100 x OD 120 x Th 4mm |
| 6. | 2419P2209 | [4] | PIN | PIN |
| 7. | 2419P2198 | [1] | PIN,100mm OD x 305mm L | KOBOD 100 x 305mm Long |
| 8. | 2419P2200 | [2] | PIN | KOB |
| 10. | 2418P14514 | [1] | TUBE | KOB |
| 11. | 2418N2674 | [1] | TUBE | KOB |
| 12. | ZX58N10100 | [2] | FLEXIBLE HOSE | KOB1000mm Long (39-3/8 in) |
| 13. | 2416P6934 | [1] | U-BRACKET | KOB |
| 14. | 2418T3887D1 | [4] | PLATE | KOB |
| 15. | 2432P824 | [12] | CLAMP | KOB |
| 16. | 2432T1213D2 | [1] | CLAMP | KOB |
| 17. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 18. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 19. | ZS18C12025 | [8] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 20. | ZS18C12075 | [1] | SCREW,Hex, M12 x 75mm | KOBM12x1.75x75mm |
| 21. | ZS18C12100 | [12] | SCREW,Hex, M12 x 100mm | KOBM12x1.75x100mm |
| 23. | ZN18C12010 | [25] | NUT | KOBM12x1.75mm |
| 24. | ZW26X12000 | [9] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 25. | ZG91S02000 | [11] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 26. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 27. | 2420T2747D2 | [1] | SHIM,102mm ID x 170mm OD x 1.2mm Thk | KOBID 102 x OD 170 x Th 1.2mm |
| 28. | 2420T2747D3 | [1] | SHIM,102mm ID x 170mm OD x 1.6mm Thk | KOBID 102 x OD 170 x Th 1.6mm |
| 29. | 2420T2747D4 | [1] | SHIM,102mm ID x 170mm OD x 2.3mm Thk | KOBID 102 x OD 170 x Th 2.3mm |
| 30. | 2420T2747D5 | [1] | SHIM,102mm ID x 170mm OD x 3.2mm Thk | KOBID 102 x OD 170 x Th 3.2mm |
| 31. | 2420T2747D7 | [1] | SHIM,112mm ID x 180mm OD x 1.2mm Thk | KOBID 112 x OD 180 x Th 1.2mm |
| 32. | 2420T2747D8 | [1] | SHIM,112mm ID x 180mm OD x 1.6mm Thk | KOBID 112 x OD 180 x Th 1.6mm |
| 33. | 2420T2747D9 | [1] | SHIM,112mm ID x 180mm OD x 2.3mm Thk | KOBID 112 x OD 180 x Th 2.3mm |
| 34. | 2420T2747D10 | [1] | SHIM,112mm ID x 180mm OD x 3.2mm Thk | KOBID 112 x OD 180 x Th 3.2mm |
| 35. | ZD12P17500 | [4] | O-RING | KOB |
| 36. | 2420R349D9 | [1] | HOSE ASSY | HOSE ASSY |
| 37. | 2420R349D240 | [1] | HOSE,2400.00 mm | KOB Superseded by part number: HX21E04240DX |
| 38. | 2420R349D175 | [1] | HOSE,6.35mm ID x 1750mm L | KOB |
| 39. | 2444T2032D2 | [2] | HYD CONNECTOR | KOBElbow, 90° -- 1/4" PF - 1/8" PT x 43mm Long |
| 40. | 2444T2032 | [1] | HYD CONNECTOR | KOBElbow, 90° -- 1/4" PF - 1/8" PT x 20mm Long |
| 41. | 2414T3655 | [1] | CLAMP | |
| 43. | ZW26X08000 | [12] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 44. | ZH22Z04000 | [3] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 45. | 2416T5904 | [1] | CLAMP | KOB |
| 46. | 2416T4333 | [4] | CLAMP | KOB |
| 47. | 2419P2206 | [2] | PIN | KOB |
| 48. | ZW16H10000 | [4] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 49. | 2419P2420 | [1] | PIN | PIN |
