神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (01-003) - REDUCTION UNIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
864 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J10363F2 | [1] | REDUCTION UNIT YS0201, LS0201 to YS0263, LS0244 | REDUCTION UNIT YS0201, LS0201 to YS0263, LS0244 |
| . . | 24100J10363F3 | [1] | REDUCER | KOBYS0264, LS0245 to YS0329, LS0336 |
| . . | 24100J10363F4 | [1] | REDUCTION UNIT YS0330, Start Serial: LS0337 | |
| 1. | 2410J272 | [1] | SHAFT | KOBYS0201, LS0201 to YS0263, YS0244 |
| 3. | ZD11G15000 | [1] | O-RING,149.30mm ID x 160.70mm OD x 5.70mm | KOB |
| 6. | ZS23C12040 | [15] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 7. | 2414J1859 | [1] | HOUSING | |
| 8. | R25P0047D13 | [1] | BEARING | KOBROLLER |
| 9. | 2418T18874 | [1] | SPACER | KOB |
| 10. | 25Z494D17 | [1] | BEARING | KOB |
| 11. | 2418T18875 | [1] | SPACER | KOB |
| 12. | 2418R2D54 | [1] | SNAP RING | KOB Superseded by part number: ZR16X12500 |
| 13. | 2401N462 | [1] | RING GEAR | KOB |
| 14. | 2401P675 | [1] | SUN GEAR | KOB |
| 15. | 2401P676 | [3] | PINION | KOB |
| 16. | 2418P20197D1 | [6] | WASHER | KOB |
| 17. | ZR16X07000 | [3] | RING | KOB |
| 10. | 2413N436F1 | [1] | SPIDER | KOB |
| 19. | 2418P20198D1 | [2] | SPACER YS0201, LS0201 to YS0269, LS0258 | SPACER YS0201, LS0201 to YS0269, LS0258 |
| . . | 2418P22951 | [2] | SPACER | KOBYS0270, Start Serial: LS0259 Superseded by part number: LS32W01006P1 |
| 20. | 2401P1149 | [1] | SUN GEAR | KOB |
| 21. | 2401P1150 | [4] | PINION | KOB |
| 22. | 2418T5454 | [8] | THRUST WASHER | KOB |
| 23. | 2413J367 | [1] | DIFF. SPIDER | KOB |
| 24. | 2410P700 | [4] | SHAFT | KOB |
| 25. | 2418T9427 | [4] | LOCKING PLATE | KOB |
| 26. | ZS23C08020 | [8] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 27. | ZS83C20030 | [3] | SCREW | KOBSet -- M20x2.50x30mm |
| 28. | 2420T6698 | [1] | PIPE | PIPE |
| 29. | ZG21U12000 | [1] | SOCKET | KOB |
| 30. | 2414J2155 | [1] | COVER | COVER |
| 31. | 2420T4730D4 | [18] | SCREW,M16 x 200mm | KOBM16x200mm |
| 32. | ZE82T08000 | [1] | PLUG | KOB1/2" PT |
| 33. | ZE82T12000 | [2] | PLUG | KOB3/4" PT |
| 34. | 2418P21405 | [1] | HOSE | KOB |
| 35. | 2418P21406 | [1] | RETAINER | KOB |
| 36. | 2418R249 | [1] | OIL SEAL | KOB |
| 37. | 2418T19867 | [1] | PLATE | KOBYS0264, Start Serial: LS0245 |
| 38. | 2418T19868 | [1] | PLATE | KOB |
| 39. | 2418R2D73 | [1] | SNAP RING | KOB |
| 40. | 2410J274 | [1] | SHAFT, PINION YS0264, LS0245 to YS0329, LS0336 | SHAFT, PINION YS0264, LS0245 to YS0329, LS0336 |
| 41. | 2410J277 | [1] | FINGER ASSY. | KOBYS0330, Start Serial: LS0337 |
